Semi-Con Removal

WS 40 Series

Motorized 5-34.5 kV Cable Semi-Con Shield Removal Tool
• Designed for removing the semi-con shield from 5 to 34.5 kV cables with diameters from 0.625″
to 1.875″ (15.88 to 47.63 mm)
• Master shaving bushings & adapter sleeves are sold separately
• Available in 115 VAC power
• Compatible with semi-con shields on XLPE, polyethylene & EPR semi-con materials

WS 40 Series Ordering Guide
REPLACEMENT BLADE
TYPE MODEL PART # CABLE O.D. OVER SEMI-CON LENGTH WEIGHT
MODEL PART #
Tool Only WS 40 17900 See Available Adapters Below N/A N/A 12″ (305 mm) 13 lb (5.1 kg)
MSBA 17938-XXX 0.600″ - 0.885″ (15.24 - 22.48 mm)
MSBB 17939-XXX 0.840″ - 1.140″ (21.34 - 28.96 mm)
CB 43 17918
MSBC 17940-XXX 1.095″ - 1.380″ (27.81 - 35.05 mm)
Adapter MSBD 17941-XXX 1.335″ - 1.485″ (33.91 - 37.72 mm) N/A 1 lb (454 g)
Sleeves
MSBD-1 17941-XXX 1.495″ - 1.635″ (37.97 - 41.53 mm) CB 43-1 17951
MSBE 17942-XXX 1.560″ - 1.650″ (39.62 - 41.91 mm) CB 43-1 17951
MSBE-1 17942-XXX 1.660″ - 1.905″ (42.16 - 48.38 mm) CB 43-2 17952

WS 40 Bushing Adapter Sleeve Reference Guide

BUSHING ADAPTER SLEEVE MODELS
MSBA MSBB MSBC MSBD MSBE
0.610″ (15.49 mm) 0.850″ (21.59 mm) 1.105″ (28.07 mm) 1.345″ (34.16 mm) 1.570″ (39.88 mm)
0.625″ (15.88 mm) 0.865″ (21.97 mm) 1.120″ (28.45 mm) 1.360″ (34.54 mm) 1.585″ (40.26 mm)
0.640″ (16.26 mm) 0.880″ (22.35 mm) 1.135″ (28.83 mm) 1.375″ (34.93 mm) 1.600″ (40.64 mm)
0.655″ (16.64 mm) 0.895″ (22.73 mm) 1.150″ (29.21 mm) 1.390″ (35.31 mm) 1.615″ (41.02 mm)
0.670″ (17.02 mm) 0.910″ (23.11 mm) 1.165″ (29.59 mm) 1.405″ (35.69 mm) 1.630″ (41.40 mm)
0.685″ (17.40 mm) 0.925″ (23.50 mm) 1.180″ (29.97 mm) 1.420″ (36.07 mm) 1.645″ (41.78 mm)
0.700″ (17.78 mm) 0.940″ (23.88 mm) 1.195″ (30.35 mm) 1.435″ (36.45 mm) 1.660″ (42.16 mm)
0.715″ (18.16 mm) 0.955″ (24.26 mm) 1.210″ (30.73 mm) 1.450″ (36.83 mm) 1.675″ (42.55 mm)
0.730″ (18.54 mm) 0.970″ (24.64 mm) 1.225″ (31.12 mm) 1.465″ (37.21 mm) 1.690″ (42.93 mm)
1.705″ (43.31 mm)
1.480″ (37.59 mm)
1.240″ (31.50 mm)
0.745″ (18.92 mm)
0.985″ (25.02 mm)
SLEEVE OUTER DIAMETER 0.760″ (19.30 mm) SLEEVE OUTER DIAMETER 1.000″ (25.40 mm) SLEEVE OUTER DIAMETER 1.255″ (31.88 mm) SLEEVE OUTER DIAMETER 1.495″ (37.97 mm) SLEEVE OUTER DIAMETER 1.720″ (43.69 mm)
1.510″ (38.35 mm)
1.270″ (32.26 mm)
1.735″ (44.07 mm)
0.775″ (19.69 mm)
1.015″ (25.78 mm)
1.285″ (32.64 mm)
0.790″ (20.07 mm)
1.525″ (38.74 mm)
1.030″ (26.16 mm)
1.750″ (44.45 mm)
1.300″ (33.02 mm)
0.805″ (20.45 mm)
1.540″ (39.12 mm)
1.765″ (44.83 mm)
1.045″ (26.54 mm)
0.820″ (20.83 mm)
1.315″ (33.40 mm)
1.075″ (27.31 mm)
1.795″ (45.59 mm)
0.835″ (21.21 mm) 1.060″ (26.92 mm) 1.330″ (33.78 mm) 1.555″ (39.50 mm) 1.780″ (45.21 mm)
1.570″ (39.88 mm)
0.850″ (21.59 mm) 1.090″ (27.69 mm) 1.345″ (34.16 mm) 1.585″ (40.26 mm) 1.810″ (45.97 mm)
0.865″ (21.97 mm) 1.105″ (28.07 mm) 1.360″ (34.54 mm) 1.600″ (40.64 mm) 1.825″ (46.36 mm)
0.880″ (22.35 mm) 1.120″ (28.45 mm) 1.375″ (34.93 mm) 1.615″ (41.02 mm) 1.840″ (46.74 mm)
0.895″ (22.73 mm) 1.135″ (28.83 mm) 1.390″ (35.31 mm) 1.630″ (41.40 mm) 1.855″ (47.12 mm)
1.150″ (29.21 mm) 1.645″ (41.78 mm) 1.870″ (47.50 mm)
1.885″ (47.88 mm)
1.900″ (48.26 mm)
1.915″ (48.64 mm)
