Page 16 - X399 AORUS Gaming 7 Rev 1.0 Introduction_170830

14.
X399 AORUS Gaming 7 Power Sequence Rev 1.0
24.
14. SPI BIOS 48MHz 32.768KHz 3.

12. Output CLK 5. 4. 3VDUAL FET

RSMRST_L A_VDD18S5
NC7SB3157 RT9018
19. APG_SVID TR4 A_V15S5 AP7365 2.

APURST-
20. VDDCR_SOC_S5 RT8068
SSAU1 PCIEX16_1
18. 22. ASM1143 USB3.1 25MHz PCIEX8_1
23.
8. 9. 21. 7. PCIEX16_2
PCIEX8_2
PCIE_RST_1 M2M_32G FET
-PSOUT PCIE_RST- PM M2P_32G
M2Q_32G
3220_CUR
3.
AP7365 6.
-PWRBTSW POWER 1.
17. 13. BUTTON
8. IT8686E PWOK 5VSB 11.
-ATX_PSON 10. ATX POWER Core power planes

SIO_WD System Voltage :
IT IT
WD_CTRL 8951E 8795EX2 1.TR4 : VCORE , VCORE_SOC ,
15. TR4 A_VDD18S5 , A_VDD1V8 , A_V15S5 ,
VDDCR_SOC_S5 , DDR12V_AB/CD ,
3VDUAL , 3VDUAL_OV,VCC3
2. PM : 3VDUAL_PM , VCC3 , PM_2V5 ,
IR35201 PM_1V05SUS , PM_1V05 .
3. SIO : VBAT , IT_VCCH , IT_AVCC
16. VCORE & VCORE_SOC ,2_5LEVEL , VREF , 28_3VSB , SIO_18V
4. DDR4 : VPP_25V_AB/CD ,
DDR12V_AB/CD , DDRVTT_AB/CD .

P.16 Dept : #41B 研發服務部 By : Engineering
