BIG LIGHT 2017 ∙ INDOOR WALL LIGHTS 161

ROUND INDI 11 ROUND INDI 22 ROUND INDI 33
LED LED LED

• 550 lumens • 620 lumens • 720-840 lumens
• Modern form creates an interesting space • Modern form creates an interesting space • Modern form creates an interesting space

Lamp details Lamp details Lamp details
LED 1x 6.5W 3000K CRI>90 LED 1x 7.5W 3000K CRI>90 LED 1x 16W 3000K CRI>90

Product details Product details Product details
120-277V 120-277V 120-277V
Total consumption: 6.5W Total consumption: 7.5W Total consumption: 16W
Material: Aluminum Material: Aluminum Material: Aluminum
Ø: 5.88 in. D: 2.6 in. Ø: 8.75 in. H: 3.71 in. Ø: 12.9 in. H: 5.29 in.
dimmable: C dimmable: C dimmable: C
Canopy Ø: 6.5 in. Canopy H: 1.5 in. Canopy Ø: 7.8 in. Canopy H: 1.5 in.

1.5 30000 2.76 30000 4.99 30000

Series available in other variants Series available in other variants Series available in other variants
Product family Indi see page 014–019. Product family Indi see page 014–019. Product family Indi see page 014–019.

5.88” 12.9”
8.75”
5.88”
7”
7” 11.25” 15.3”

2.6”
2.6”

Variant Item No. Variant Item No. Variant Item No.
550lm 620lm 720lm
Black/Gold 701010U Black/Gold 701020U Black/Gold 701030U
White 701011U White 701022U 840lm
White 701033U
