158 WALL LIGHTS INDOOR · BIG LIGHT 2017

BIG ROX BIG ROX
Up/Down 15 Down 7.5

• 1447 lumens up and 1447 lumens down • 1387 lumens
• Architectural LED wall mounts • Architectural LED wall mounts
• Contemporary up/down design • Contemporary design

Lamp details Lamp details
LED 2x 13W 3000K CRI>80 LED 1x 13W 3000K CRI>80

Product details Product details
120-277V 120-277V
Total consumption: 26W Total consumption: 13W
Material: Aluminum/Glass Material: Aluminum/Glass
Ø: 4.92 in. H: 7.28 in. D: 6.14 in. Ø: 4.92 in. H: 5.2 in. D: 6.14 in.
dimmable: C dimmable: C
Canopy Ø: 6 in. Canopy H: 0.5 in. Canopy Ø: 6 in. Canopy H: 0.5 in.

24° 3.92 24° 2.87 30000

30000
Series available in other variants Series available in other variants
Product family Rox see page 014–019. Product family Rox see page 014–019.

4.92” 4.92”

5.20”
7.28”
6.14”
6.14”

Variant Item No. Variant Item No.
2894lm 1387lm
White 751761U White 751771U
Anthracite 751764U Anthracite 751774U
Bronze 751768U Bronze 751778U
