Page 134 - TCD Catalog 2017

TCD Parts Inc.

ADS Electrical

START SWITCH DOOR CUTOFF SWITCH
MODEL ASQ FOR ADS

Part # Description ADS # Part # Description ADS #
90-0112 START SWITCH ASSEMBLY (GREEN) 091-3031 90-1140 DOOR CUT OFF SWITCH 099-4502
90-0113 START SWITCH ASSEMBLY (RED)- 091-3041
DOOR CUT OFF
90-0114L RED LENS FOR START SWITCH 091-3043
FOR ADS
90-0118L GREEN LENS FOR START SWITCH 091-3033

CONTACTOR

Part # Description ADS #
90-1142 DOOR CUT OFF PLUNGER HEAD WITH ROLLER 099-4501
ONLY
Part # Description ADS #
90-0902 CONTACTOR MOTOR RELAY 25 AMP 091-3083 CONTACT BLOCK

CONTACT BLOCK

Part # Description ADS #
90-0120 CONTACT BLOCK, ET-AF & HT-25 091-3065
Part # Description ADS # OPERATOR SWITCH
90-0186 CONTACT BLOCK SWITCH - CAROUSEL 091-3036
GLASSWASHER
FUSES

Part # Description ADS #
90-0121 OPERATOR SWITCH, ET-AF & HT-25 091-3067
Part # Description ADS #
90-0172 FUSE 10 AMP 391-9102 BULB FOR ADS
90-0174 FUSE, PRIMARY 3AMP/3PHASE 291-9101
90-0175 FUSE, SECONDARY 1 6/103 PHASE 291-9102

Part # Description ADS #
90-0190 INDICATOR BULB 391-7101

www.tcdparts.com 133
Customer Service (800) 823-8313
