TCD Parts Inc.

Foot Valves

SUPER FLOW FOOT DIAPHRAGM FOOT
VALVE VALVE

Part # Description
Part # Description FV-100-16V 1/4”—3/8” FOOT VALVE DIAPHRAGM VITON SEAL;
CHLORINE USE
FV-200 VITON DIAPHRAGM; 1/2” FPT; W/O SCREEN; W/O BARB CONN
FV-200-V VITON DIAPHRAGM; 1/2” FPT; W/O BARB CONN; W/ SCREEN BALL & SPRING
FV-201-V VITON DIAPHRAGM; 1/4” BARB CONN; W/SCREEN FOOT VALVE
FV-202-V VITON DIAPHRAGM; 3/8” BARB CONN; W/ SCREEN
FV-203-V VITON DIAPHRAGM; 1/2” BARB CONN; W/ SCREEN
Part # Description
BETA STYLE FOOT FV-1PCV 1/4”, 3/8” & 1/2” FOR CHLORINE & SOLVENT USE; TEFLON
VALVE BALL VITON O-RING; POLYPROPYLENE
FOOT FILTER

Part # Description
BT-1200932 INLINE FOOT VALVE VITON 1/4”, 3/8”, & 1/2”
Part # Description
FV-1PS 1/4”, 3/8” & 1/2” FOOT FILTER—NO CHECK VALVE

HYDRO STYLE
FOOT VALVE

Part # Description
FV-102 PVC 1/4”, 3/8”, 1/2” FOOT VALVE VITON SEAL;
CHLORINE USE
CERAMIC WEIGHTS

Part # Description
61-0102 WEIGHT FOR 1/4”-3/8” OD TUBING 3” IN LENGTH
61-0103 WEIGHT FOR 3/8”-1/2” OD TUBING 3” IN LENGTH

www.tcdparts.com 129
Customer Service (800) 823-8313
