Spray Arm Parts

SPRAY ARMS FOR ADS/CMA SPRAY ARM NOZZLES
FOR ADS/CMA

Part # Description
66-2001-4 SPRAY ARM NOZZLE #4
66-2001-5 SPRAY ARM NOZZLE PUSHER #5

FINAL RINSE NOZZLE
FOR CMA

Part # Description ADS # CMA # Part # Description CMA #
66-301 SINGLE RACK SPRAY ARM 081-6204 00304.06 66-0056 SS NOZZLE FOR CMA 44, 1/16” NPT 02101.01
23” LONG (NOT FOR “L” OR
3D-S SERIES)
66-302 DOUBLE RACK SPRAY ARM 081-6205 00304.03
20” LONG SPRAY ARM END CAPS
66-306 UNDERCOUNTER FOR ADS 081-6208
ET-AF - 20 3/8”
66-319 UNDERCOUNTER CROSS 081-6212
ARM 19 1/2”
66-321 UNDERCOUNTER CROSS 081-6212 Part # Description ADS # CMA #
ARM 21”
66-101 SS END CAPS 084-6211 308.50
FINAL RINSE NOZZLES 66-102 BRASS END CAPS 084-6203
FOR ADS/CMA CM-00308.20 CMA END CAPS FOR 308.20
UNDERCOUNTER

V-JET NOZZLES

Part # Description ADS # CMA #
66-19004-P Hydex material - 1/8” NPT 284-6145 13304.50
66-19004-SS Stainless Steel - 1/8” NPT 284-6146 13304.50

FINAL RINSE NOZZLES FOR Part # Description
HIGH TEMP ADS/CMA 66-6175-2 STAINLESS STEEL 1/8” NPT 80-10; .050 x 45°
66-6185 STAINLESS STEEL 1/8” NPT 80-20; .080 X 60°

Part # Description ADS # CMA #
66-6121-070 SS - 1/16” NPT; .070 HOLE 384-6121 13304.55
SPRAY JETS
