Pneumatic Ventilator
Features DIMENSIONS
• CFM rating of 2,063
• Lightweight, only 28 lbs. MODEL 3000P
• Stackable to save storage or Fan Type
work area space Axial Blower/Extractor CONFINED SPACE VENTILATION F-2
• Powerful 1.5 hp electric motor Size 12" dia. (305mm)
• Capability to connect up to 125 Weight 28 lbs. (12.7kg)
feet (38m) of straight duct Height 21" (533mm)
• Ideal for confined spaces that
require greater airflow Length 17" (432mm)
• UL & CUL listed Width 14" (355mm)
For confined spaces that require a
powerhouse air ventilator, the UAF-
3000 can handle your most demanding industrial needs. AIR FLOW RATES
MODEL 3000P
With a forceful 1.5 hp motor, the UAF-3000 can deliver both positive
and negative airflow at an incredible maximum capacity of 2,063 CFM CFM M³/Min.
in the most difficult work environments. No matter what your industry or Free Air 2,063 58.4
application construction, demolition, utility, paper mill, shipyard, power 15' straight 1,753 49.6
station, tank purging, or manufacturing — the UAF-3000 is designed to
take on the toughest jobs. 15' 1-90 bends 1,616 45.7

Also Available! UAF-3000FRL 15' 2-90 bends 1,450 41.0
For hazardous space applications where air compressors or built-in air 25' straight 1,619 45.8
lines are the preferred choice of power, turn to the UAF-3000FRL. 25' 1-90 bends 1,497 42.4

With its built-in FRL Unit (Filter, Regulator, Lubricator), you will breath 25' 2-90 bends 1,433 40.6
easier and your UAF-300FRL will operate more efficiently. 50' straight 1,531 43.3
VPN: A-3000P 100' straight 1,243 35.2

High Capacity Ventilator
DIMENSIONS
Features MODEL 8000
• CFM rating of 9,968
• Weighs only 119 lbs. (53.97kg) Fan Type Axial Blower/Extractor
• Powerful 5 hp electric motor Size 20.5" dia. (520mm)
• Two built-in handles Weight 119 lbs. (53.97kg)
• Dual-wall shell design
• Ideal for larger areas that require Height 27.5" (698mm)
greater airflow Length 27.5" (698mm)
Width 25.5" (647mm)

Designed for use in areas that require a greater exchange of air, the AIR FLOW RATES
UAF-8000 promises performance. MODEL: 8000 A

Equipped with a powerful 5 hp motor, the UAF-8000 generates both CFM M³/Min
positive and negative airflow at an outstanding maximum capacity Free Air 9968 282.3
of 9,968 CFM. Hold onto your seat, this 20.5 inch unit outperforms 25' straight 9379 256.6
ventilators three or four times its size. If you’re in need of a ventilator for 25' 1-90 bends 7193 203.7
larger applications, turn to the one that provides extreme performance,
turn to the UAF-8000. 25' 2-90 bends 6726 190.5
50' straight 8664 245.3
VPN: VAF-8000 75' straight 8313 235.4
