Control of Industrial Major Accident Hazards (CIMAH) Report Page 40
Ranhill SAJ Sdn. Bhd. Revision 01
Part D: Information on the Potential Major Accident Date Aug 2019

Consequence
Hazardous Concentration
Major Accident Scenario Location Maximum Affected Area
Substances (ppm)
Distance (m)
Onsite
Staff quarters
Taman Kekwa
Teck Seng Food Industries
Rattan Factory
10 1159.94 Guan Kiat Palm Oil Enterprise
(IDLH)
Chlorine Cylinder Catastrophic Kampung Padang Lalang
Failure / Rupture Chlorine KT1 Chlorine Taman Mega
Room
(Door Opened) Taman Emas
Taman Segar
Taman Tasik
495 Chlorine Room
(50% fatality) 47.4 Administration Office
4827
(100% fatality) 4.49 Chlorine Room
Onsite
Staff quarters
Taman Kekwa
Teck Seng Food Industries
Rattan Factory
Chlorine Cylinder 50mm Hole KT1 Chlorine 10
Diameter Leak (Door Opened) Chlorine Room (IDLH) 1084.62 Guan Kiat Palm Oil Enterprise
Kampung Padang Lalang
Taman Mega
Taman Emas
Taman Segar
Taman Tasik
