CONSTRUCT

C3.13 Cubicles C3.14 IPS Panels

All cubicle systems must be provided in compact Where replacement or new IPS panels are
laminate using the following finishes: required, these should be supplied as balanced
laminate on 12mm WR MDF core with postformed
Doors edges to the vertical sides.
Polyrey D018 Chêne De Maymac F/A
IPS panels must be full height, starting +110mm
Side walls AFFL and finishing at +2100mm AFFL broken into
Polyrey M003 Maryland Fonce F/A. two panels.

Cubicles must be supplied with all ironmongery Urinal IPS panels to start at +110mm AFF and
including rising hinges, locking devices with finish at +1200mm AFFL.
indicators, coat hooks, door stops and propriety
mounting clips, feet and rails. Fixings to be concealed, using semi permanent
push clip fixings at min 600mm centres along
the vertical edges.

C3.13 Cubicles 1.0 08 October 2014
C3.14 IPS Panels 1.0 08 October 2014
