PROJECT NAME : يبرحلا ريبوج ةزيزع لايف WALL MOUNTED PANEL : IP-42
DISTRIBUTION BOARD NAME : DB-OUT 1 INCOMMING FEEDER : CABLE (3*16+16)+16mm
MAIN INCOMING CIRCUIT BREAKER : 3PH MCCB C.B 40 AMP. CU/PVC/PVC
SHORT CIRCUIT BREAKING CAPACITY 25KA COPPER CONDUCTORS
FIRST FLOOR
C.B WIRE LOAD/PHASE IN VA ADDED NO C.B PHASE C.B NO ADDED LOAD/PHASE IN VA WIRE C.B
OF CONNECTION OF LOAD DESCRIPTION
NO. SIZE,CU R Y B UNITS RATING RATING UNITS R Y B SIZE,CU NO.
MM2 POLES AMP. R Y B AMP. POLES MM2
1 LIGHTING L1 3x3 90 1P 16A 20A 1P 405 3x3 L12 LIGHTING 2
3 LIGHTING L2 3x3 375 1P 16A 20A 1P 450 3x4 S1 SOCKET 4
5 LIGHTING L3 3x3 325 1P 16A 20A 1P 1000 3x4 S2 SOCKET 6
7 LIGHTING L4 3x3 675 1P 16A 20A 1P 1300 3x4 S3 SOCKET 8
9 LIGHTING L5 3x3 375 1P 16A 20A 1P 500 3x4 S4 SOCKET 10
11 LIGHTING L6 3x3 500 1P 16A 20A 1P 450 3x4 S5 SOCKET 12
13 LIGHTING L7 3x3 150 1P 16A 20A 1P 300 3x4 S6 SOCKET 14
15 LIGHTING L8 3x3 90 1P 16A 32A 1P 300 3x4 S7 SOCKET 16
17 LIGHTING L9 3x3 135 1P 16A 32A 1P 3915 3x6 A.C1 A/C UNIT 18
19 LIGHTING L10 3x3 90 1P 16A 32A 1P 2237 3x6 A.C2 A/C UNIT 20
21 LIGHTING L11 3x3 90 1P 16A 25A 1P 1500 3x6 W.H1 WATER HEATER 22
23 SPARE __ 1P 16A 20A 1P __ SPARE 24
25 SPACE - 1P __ __ 1P SPACE 26
1005 930 960 R Y B 4242 2750 5365
MAIN C.B 1005 930 960
40 A 5247 3680 6325
MCCB TOTAL 15252
NOTES :- 25KA
CT : CONTACTOR WITH TIMER & P.B Ics=100% Icu FULL LOAD AMP/PH DEMAND LOAD KVA/PH MAX. DEMAND AMP
CTT : CONTACTOR WITH TIMER & PHOTO CELL R Y B R Y B 19.94
ELR : EARTH LEAKAGE 30 mA 23.85 16.73 28.75 3.28 2.19 4.39
MAX. FULL LOAD AMP DEMAND AMP/PH
28.75 AMP 14.92 9.94 19.94
CONNECTED LOAD LIGHTING SOCKET P/SOCKET AIR CONDITION F.C.U WATER HEATER OTHERS TOTAL
LOAD IN VA 3300 4300 0 6152 0 1500 0 15252
DEMAND FACTOR 0.9 0.9 0.9 0.9 0.8 0.9 0.8 0.80 DB-OUT 2
ACTUAL LOAD 2970 3870 0 5536.8 0 1350 0 13726.8 PANEL
