PROJECT NAME : يفايعلا نسح لايف WALL MOUNTED PANEL : IP-65
DISTRIBUTION BOARD NAME : MDB INCOMMING FEEDER : CABLE (3*95+50)+50mm
MAIN INCOMING CIRCUIT BREAKER : 3PH MCCB C.B 200 AMP. CU/XLPE/PVC
SHORT CIRCUIT BREAKING CAPACITY 25KA COPPER CONDUCTORS
GROUND FLOOR
C.B WIRE LOAD/PHASE IN VA ADDED NO C.B PHASE C.B NO ADDED LOAD/PHASE IN VA WIRE C.B
OF CONNECTION OF LOAD DESCRIPTION
NO. SIZE,CU R Y B UNITS RATING RATING UNITS R Y B SIZE,CU NO.
MM2 POLES AMP. R Y B AMP. POLES MM2
1 15474 3275 2
CABLE CABLE
3 DB-G LOAD (3*25+16)+16m 14482 3P 80A 25A 3P 2900 (3*10+10)+10m LOAD DB-OUT 4
m m
5 10705 4708 6
7 11457 2095 8
CABLE CABLE
9 DB-F LOAD (3*25+16)+16m 11039 3P 80A 25A 3P 4586 (3*10+10)+10m LOAD DB-R 10
m m
11 14778 4343 12
13 2000 14
15 WATER PUMP LOAD 4*10 2000 3P 3P SPACE 16
17 2000 18
19 20
21 SPARE 3P 3P SPACE 22
23 24
28931 27521 27483 R Y B 5370 7486 9051
MAIN C.B 28931 27521 27483
200 A 34301 35007 36534
MCCB TOTAL 105842
NOTES :- 25KA
CT : CONTACTOR WITH TIMER & P.B Ics=100% Icu FULL LOAD AMP/PH DEMAND LOAD KVA/PH MAX. DEMAND AMP
CTT : CONTACTOR WITH TIMER & PHOTO CELL R Y B R Y B 132.85
ELR : EARTH LEAKAGE 30 mA 155.91 159.12 166.06 27.44 28.01 29.23
MAX. FULL LOAD AMP DEMAND AMP/PH
166.06 AMP 124.73 127.30 132.85

CONNECTED LOAD LIGHTING SOCKET P/SOCKET AIR CONDITION F.C.U WATER HEATER OTHERS TOTAL
LOAD IN VA 0 0 0 0 0 0 105842 105842
DEMAND FACTOR 0.8 0.9 0.9 0.85 0.8 0.5 0.9 0.90 MDB
ACTUAL LOAD 0 0 0 0 0 0 95257.8 95257.8 PANEL
