P. 34

DOWNLIGHT 4INCH







                                                         The new EnVision architectural retrofit
                                                         downlight surpasses other recessed lights on
                                                         the market. With a depth of .55 inches the

                                                         downlight is focused on decreasing any glare
                                                         from the LED chips. At 750 Lumens, and fully
                                                         dimmable, you have plenty of light when

                                                         desired. The light turns on instantly, and is not
                                                         affected by frequent on/off switching.





                                                         Applications:

                                                         • Recessed Downlighting

                                                         • New Construction

                                                         • Residential Lighting
                       4 inch (can)
                                                         Product Information:
                                                         • Increase energy savings and shorten payback period

                                                         • High intensity: ready to replace existing 75w halogens

                                                         • Title 24 (Ideal) Connector Plug
                                          2.11 inch
                                                         • Dimmable: Compatible with most dimmers down to 5%
                                                         • Fits most 4inch cans
                                            Includes
                                           E26 Converter
                                                                                                           Beam
            Type            Model                  Volt         Watt      Lumen Color             CRI     Spread


             4INCH     LED-ADL-4-10W-27K            120V          10W       750      Soft- 2700k  >90        120°

             4INCH     LED-ADL-4-10W-30K            120V          10W       750      Warm- 3000k  >90        120°

             4INCH     LED-ADL-4-10W-40K            120V          10W       750      Cool- 4000k  >90        120°

             4INCH     LED-ADL-4-10W-50K            120V          10W       750      Day- 5000k   >90        120°

        CEC/ JA-8 Listed and tested at 665 Lumens

                                                                         JA-8
        EnVision LED Lighting, Inc.
        801 E Washington Blvd. | Los Angeles, CA 90021 | P: 213-741-1550 | www.envisionledlighting.com31  Compliant
