Page 33 - Envision E-Catalog

DOWNLIGHT 3INCH

The new EnVision architectural retrofit
downlight surpasses other recessed lights on
the market. With a depth of .50 inches the

downlight is focused on decreasing glare and
achieving full performance from the LED’s. At
550 Lumens, CRI >90, and fully dimmable, you

have plenty of light when desired. The light
turns on instantly, and is not affected by
frequent on/off switching.

Applications:

• Recessed Downlighting

• New Construction

• Residential Lighting
3 inch (can)
Product Information:
• Increase energy savings and shorten payback period

• High intensity: ready to replace existing 50w halogens

• Title 24 (Ideal) Connector Plug
2.1 inch
• Dimmable: Compatible with most dimmers down to 5%
• Fits most 3inch cans
Includes
E26 Converter
Beam
Type Model Volt Watt Lumen Color CRI Spread

3INCH LED-ADL-3-8W-27K 120V 8W 550 Soft- 2700k >90 120°

3INCH LED-ADL-3-8W-30K 120V 8W 550 Warm- 3000k >90 120°

3INCH LED-ADL-3-8W-40K 120V 8W 550 Cool- 4000k >90 120°

3INCH LED-ADL-3-8W-50K 120V 8W 550 Day- 5000k >90 120°

Downlight will be available approx. 5/2016. Specs are subject to change.

JA-8
EnVision LED Lighting, Inc.
801 E Washington Blvd. | Los Angeles, CA 90021 | P: 213-741-1550 | www.envisionledlighting.com 30 Compliant
