Grandtrek AT20

80% ON-ROAD; 20% OFF-ROAD
Fitted as Original Equipment on the Toyota Prado and other leading 4WDs, the Dunlop
Grandtrek AT20 features an advanced tread design allowing excellent performance on
a wide variety of surfaces. The AT20 also features a reinforced construction to minimise
the risk of side wall damage, providing the confidence you need on and off road.

Braking Handling
Performance Performance Low Noise Durability

FEATURES BENEFITS
Silica-based tread compound Superior braking, cornering and handling.
Also reduces rolling resistance, which can
enhance fuel economy
Jointless Band Technology™ Superior steering response, braking efficiency
and even wear
4WD/RV/SUV
Multi-pitch tread design technology Helps reduce noise for a quiet ride
Original Equipment Endorsed by leading 4WD manufacturers

TYRE SIZE SERVICE SECTION WIDTH OVERALL STATIC REVS PER SINGLE MAX APPROVED OE FITMENTS
DESIGNATION DESCRIPTION (MM) ON DESIGN DIAMETER LOADED KILOMETRE LOAD (KG) AT MAX RIM WIDTH
RIM (MM) RADIUS PRESSURE (PSI) (INCHES)
(MM)
ALL TERRAIN
245/70R16 111S 248 on 7" 753 337 438 1090 @ 36 6 1/2 - 8 Mitsubishi Triton, Isuzu D-Max
255/70R16 111H 260 on 7 1/2" 764 347 432 1090 @ 36 6 1/2 - 8 1/2 Mazda BT50, Nissan Navara
265/70R16 112S 272 on 8" 778 354 424 1120 @ 36 7 - 9 Mitsubishi Pajero Sport
275/70R16 114H 279 on 8" 792 360 416 1180 @ 36 7 - 9 Toyota Land Cruiser
225/70R17 108S 228 on 6 1/2" 748 340 441 1000 @ 42 6 - 7 1/2 Toyota Hilux
265/65R17 112S 272 on 8" 776 353 425 1120 @ 36 7 1/2 - 9 1/2 Toyota Land Cruiser Prado
275/65R17 115H 279 on 8" 790 359 417 1215 @ 36 7 1/2 - 9 1/2 Nissan Patrol
265/60R18 110H 272 on 8" 750 341 440 1060 @ 36 7 1/2 - 9 1/2 Mitsubishi Pajero
