Grandtrek AT23

80% ON-ROAD; 20% OFF-ROAD

This Original Equipment tyre is specified for its quiet and smooth ride, stability and
durability.

Wet
Performance Fuel Durability
Economy
FEATURES BENEFITS

Silica tread compound Superior braking, handling and cornering in all
conditions
Robust casing construction Offers protection against road hazards
Original Equipment Endorsed as Original Equipment by leading
vehicle manufacturers

4WD/RV/SUV
TYRE SIZE SERVICE SECTION WIDTH OVERALL STATIC REVS PER SINGLE MAX APPROVED OE FITMENTS
DESIGNATION DESCRIPTION (MM) ON DESIGN DIAMETER LOADED KILOMETRE LOAD (KG) AT MAX RIM WIDTH
RIM (MM) RADIUS PRESSURE (PSI) (INCHES)
(MM)
275/60R18 113H 279 on 8" 787 358 419 1150 @ 36 7 1/2 - 9 1/2 Toyota Land Cruiser

ALL TERRAIN

Grandtrek AT25

80% ON-ROAD; 20% OFF-ROAD
Designed to meet the exacting needs of new vehicle manufactures and deliver low noise
and all-terrain durability.

Handling
Durability Performance Low Noise

FEATURES BENEFITS
Refined tread pattern design Low road noise
Ribbed tread pattern Competent road handling

Durable carcass design Reliable all-terrain performance

TYRE SIZE SERVICE SECTION WIDTH OVERALL STATIC REVS PER SINGLE MAX APPROVED OE FITMENTS
DESIGNATION DESCRIPTION (MM) ON DESIGN DIAMETER LOADED KILOMETRE LOAD (KG) AT MAX RIM WIDTH
RIM (MM) RADIUS PRESSURE (PSI) (INCHES)
(MM)
255/65R17 110S 253 on 7 1/2 743 331 444 1060 @ 36 7 - 9 Isuzu D-Max
255/60R18 108H 260 on 7 1/2 789 359 418 1000 @ 36 7 - 9 Isuzu D-Max

265/60R18 110H 272 on 8 750 341 440 1060 @ 36 7 1/2 - 9 1/2 Misubishi Pajero
265/60R18 110H 272 on 8 750 341 440 1060 @ 36 7 1/2 - 9 1/2 Toyota Hilux SR5 Cruiser

285/60R18 116V 292 on 8 1/2 802 360 411 1250 @ 36 8 - 10 Lexus LX470D

Raised white letters

82
