Engine Re-Ring Kits High-Performance Oil Pumps
By Schumanns
New iron alloy pumps are cast with 80% less porosity for
a yield strength of 70,000 PSI. Pumps are blueprinted and
precisely machined with full flow shaft oiling, exact mesh
gears and anti-aeration bleed-off for exceptional high RPM
lubrication. Choose “O.E. Plus”, or the “Sportsman SSR” series
which includes 50-55, 65-70 and 80-90 PSI pressure relief springs.
Description O.E. Plus Sportsman SSR
Small Block Chevy 262-400
Standard Volume AFM20315 AFM20317
High Volume AFM20316 AFM20318
Ideal for street or entry level drag racing, Re-Ring Kits include Clevite 77 High Volume, Quick Change Relief Spring — AFM20319 †
main and rod bearings, Fel-Pro gasket set, and choice of Sealed Power cast Standard Volume, 3/4" Pickup AFM20320 —
or moly piston ring set. Please specify piston, ring, and bearing sizing when High Volume, 3/4" Pickup — AFM20322
ordering. Big Block Chevy 396-454 AFM20328 —
Standard Volume
Cast Ring Moly Small Block Ford 289-351W
Application Re-Ring Kit Re-Ring Kit Standard Volume AFM20323 —
SB Chevy 350, 1967-85 AFM09350 AFM09350-1 High Volume AFM20324 AFM20325 ‡
SB Chevy 400 AFM09400 AFM09400-1
BB Chevy 454 — AFM09454-1 †Includes anti-cavitation plate.
‡Gear pressure balanced to prevent hydraulicing.
SB Ford 302 AFM09302 AFM09302-1
SB Ford 351W — AFM09351W-1
Small Block Chevy
GM LS Series High-Volume/High-Performance Oil Pump Pressure Relief Springs
Oil Pump By Schumanns Engineered for AFM high performance oil pumps.
GM LS Series oil pump is engineered Part No. Description
for applications with up to 500 AFM20313 Pressure Relief Spring, 65-70 PSI
horsepower and includes an oversized, AFM20314 Pressure Relief Spring, 80-90 PSI
9/16" ID outlet port to block with an O-ring Heavy-Duty Engine Stand
seal. Pump additionally features machined AFM10175
and radiused internal oil passages for increased oil flow. Sold complete with Heavy Duty Engine Stand features an
three color-coded pressure relief springs in 60, 70 and 80 PSI ratings. “I”-shaped base with support through
Part No. Description
AFM20330 GM LS Series Oil Pump the center and a 1,000 lbs. capacity.
GM LS Oil Pump-To-Crank Center Alignment Tool Kit, Maximum Capacity Length Width Height Weight
AFM20331
Aids Pump Installation 1,000 lbs. 32" 30" 30" 52 lbs.

LSX Mongoose
Aluminum Cylinder Heads
Engineered as the ultimate bolt-on for 1997-up
Single-Plane Aluminum LS-series engines, emissions-legal Mongoose
Manifolds 205cc and 225cc aluminum cylinder heads of-
Aluminum single-plane intake AFR4901 fer unmatched flow and performance. The small port
manifolds feature an isolated runner 205cc street head offers 70 CFM of increased air flow compared to OEM
design for improved performance. castings and works well on 346-396 cu. in. applications, while the 225cc
Choose from manifolds with and 260cc versions are better suited to larger, 396-427 cu. in. engines. All
standard 4150 or 4500 Dominator carb flange. heads are sold in pairs, completely assembled with stainless valves, valve
Part No. Description springs, retainers, locks, and seals.
AFR4811 SB Chevy 23° Eliminator, 4150 Flange Intake Comb. Int. Exh.
AFR4901 BB Chevy Tall Deck 18° Magnum, 4500 Flange Part No. Description Runner Chamber Valve Valve
AFR4902 BB Chevy Std. Deck 18° Magnum, 4500 Flange AFR1510 Street-Legal Mongoose Assem. 205cc 66cc 2.020" 1.600"
AFR4992 BB Ford 429-460, 4150 Flange AFR1630 Street/Strip Mongoose Assem. 225cc 72cc 2.080" 1.600"
AFR4993 BB Ford 429-460, 4500 Flange AFR1840 § Strip Mongoose Assem. 260cc 69cc 2.165" 1.600"
§Includes titanium retainers.
