2020 DRAG RACING

Main Cap Support Girdles Coolant Catch Tank
Laser-cut, chrome moly steel girdles CAN80-205
tie all five main caps together Designed to prevent overflow coolant from spilling onto the race
to strengthen the bottom end of CAN21-060 track, fabricated aluminum tank is 3-1/4" dia. x 9" high and has a
popular Ford V8’s. Girdles clear large strokers and don’t require machining, 24 oz. capacity. Sold complete with petcock and mounting clamp.
bushings or spacers to mount. Hardware included. Louvered steel windage
trays for use with main cap girdles are also available. Coolant Recovery Tanks
Application Main Cap Support Girdle Windage Tray Model specific coolant recovery tanks are fabri-
SB Ford 289-302 CAN21-060 CAN20-960
SB Ford 351W CAN21-062 CAN20-962 cated from .100" aluminum and are much more
BB Ford 429-460 CAN21-066 CAN20-966 durable than OEM plastic units.
Part No. Description
Fabricated Aluminum Valve Covers CAN80-224 1984-96 Corvette
CAN80-225 1997-04 Chevy Corvette
Tall, fabricated aluminum valve cov- CAN80-230 1987-93 Ford Mustang V8
ers are plain with no holes and will CAN80-231 1994-95 Ford Mustang V8
1996-04 Ford Mustang V8
CAN80-232
clear roller rockers and stud girdles. CAN80-236S 2005-09 Ford Mustang V8, 2011-14 GT 500, Stock Style Neck
Sold in pairs with stainless steel CAN80-246S 2011-14 Ford Mustang V8, Radiator Cap Style NEW!
mounting hardware. CAN80-247S 2015-Up Ford Mustang With Stock Neck NEW!
Part No. Description
CAN65-200 SB Chevy 265-400 Supercharger Coolant Tanks
CAN65-201 SB Chevy 265-400, Includes (1) Fill Bung And (2) PCV Holes Designed specifically for supercharged Mustangs,
CAN65-206 SB Chevy 305-350, 1993-97 “F”- Body Design
CAN65-208 SB Chevy 350 Centerbolt, 1992-96 Corvette Replacement fabricated .100" aluminum tanks replace stock units.
CAN65-300 SB Ford 289-351W Part No. Description
CAN65-385 BB Ford 429-460 CAN80-233S 2003-04 Ford Mustang Cobra, Stock Style Neck
CAN65-400 BB Chevy 396-454 CAN80-239 2005-Up Ford Mustang, Vortech/Paxton Style System
Fuel Pump Block-Off Plates Fuel Cooling Ice Tank
Billet aluminum plates are used to block-off the fuel CAN80-500
pump opening when a mechanical pump is not used. Fabricated 3-1/4 qt. capacity aluminum tank, designed
Black anodized finished. to be packed with ice, incorporates 8' of spiraled alumi-
Part No. Description num 3/8" dia. tubing. Large removable cap allows easy
CAN21-954 Big Block Chevy, Ford (Exc. 351C, 351M-400), Chrysler filling. Tank includes 3/8"NPT inlet and outlet ports, and a 3/8"NPT drain plug.
CAN21-960 Pontiac, 1969-Up
CAN21-964 Oldsmobile/Cadillac
Phenolic Carburetor Spacers
Chevy Universal Alternator Mounting Bracket Phenolic carburetor spacers increase the barrel/plenum size and insulate the carbure-
CAN75-220 tor from the manifold for a denser fuel mixture. Available in four-hole or open styles.
Rigid billet aluminum bracket accepts GM, Part No. Description
Honda, ND, and Mitsubishi alternators, and 4-Hole Holley Spacers
1" Thick Spacer For 4150/4160 Carb
positions the alternator to the right side of CAN85-150 1/2" Thick Spacer For 4150/4160 Carb
CAN85-152
the water pump. Gold anodized bracket in- CAN85-154 1/4" Thick Spacer For 4150/4160 Carb
cludes hardware and may be easily adapted CAN85-158 1" Thick Spacer For 4150/4160 Carb, Blended
1" Thick Spacer For 4500 Carb
to other applications. CAN85-210 1/2" Thick Spacer For 4500 Carb
CAN85-212
Open Style Holley Spacers
CAN85-160 1" Thick Spacer For 4150/4160 Carb
Billet Aluminum 90° Water Necks
CAN85-162 1/2" Thick Spacer For 4150/4160 Carb
Rigid billet aluminum water necks feature a 360° CAN85-200 1" Thick Spacer For 4500 Carb
CAN80-051
1/2" Thick Spacer For 4500 Carb
CAN85-202
rotating design (unless noted) that provide desired radiator hose routing. 4-Hole Rochester Quadrajet Spacer
Water necks accept 1-1/2" dia. radiator hose and are sold complete with CAN85-250 1" Thick Spacer For Q-Jet
stainless fasteners.
Part No. Description Carb Mounting Studs
CAN80-051 Pontiac 326-455 Stainless steel stud kits include four studs with locking flange nuts.
CAN80-052 GM LS1/LS6
CAN80-056* Small Block Ford 302-351W Designed for use with Holley-style carburetors.
CAN80-057 Ford 351C, 429-460 Part No. Description
CAN80-059 Ford Modular 4.6/5.4L NEW! CAN85-500 1-1/2" Long 5/16"-18, Use When Not Using Carb Spacer
CAN80-058 Big Block Ford 390-428 “FE” CAN85-510 2" Long 5/16"-18, Use With 1/2" Carb Spacers
*Water neck is fixed due to incorporated 3/4" heater hose fitting. CAN85-520 2-1/2" Long 5/16"-18, Use With 1" Carb Spacers
CAN85-530 4" Long 5/16"-18, Use With 2" Carb Spacers
