Heavy-Duty Stain less Bolt-On Diagonal Link Bracket
T-Bolt Band Clamps Made from 3/16" mild steel with 1/2" and 5/8" or
Made from the highest quality stain less steel 3/4" holes.
with a stainless T-bolt and Nylock lock nut for positive clamping that can’t Part No. Description
come loose. CCE3748-1 Bracket, 1/2" And 5/8" Holes
CCE3748-2 Bracket, 1/2" And 3/4" Holes
Part No. Description
CCE2152 1.25" To 1.37" Clamp
CCE2157 1.56" To 1.70" Clamp Ladder Bar Housing Bracket
CCE2173 2.56" To 2.87" Clamp CCE3607-2
Used on newer style Chassis Engineering ladder bars, 1/4"
Quick Release Pins
mild steel bracket has 5/8" holes and 3" cutouts.
Use on any components that must be removed or discon-
nected quickly. A push button operates the locking ball Ladder Bar Frame Bracket
mechanism which provides positive retention.
CCE3638-3
Part No. Diameter Grip
CCE2035 3/8" 1" Mount ladder bars to frame. Bracket is 5-1/2"
CCE2045 3/8" 2" x 8" and 3/16" thick.

Heavy-Duty Four-Link Frame Bracket

CCE3500-9
Ladder Bar Crossmember Bracket
Frame mount bracket is 4" x 12-1/2" with 3/4" holes and CCE3718-1
is manufactured from 1/4" thick mild steel. For cars under Replacement bracket for CCE3718 lad der bar
2,400 lbs.
crossmember. Bracket is 5-1/2" x 6", 1/8"
thick mild steel with five 3/4" holes and one
Heavy-Duty Four-Link Housing Brackets
1-3/4" hole.
Heavy-duty, 1/4" steel housing mount bracket is 5-3/4"
x 12-1/4" with 3/4" holes. Brackets are offered with or Ladder Bar Housing Bracket
without provisions for shock mounting. With Shock Mount
Part No. Description CCE3607-9
CCE3514-1 Housing Bracket With Shock Mount
CCE3514-2 Housing Bracket Without Shock Mount Housing mount bracket is made from 1/4" thick
mild steel with 5/8" ladder bar mounting holes
“Top Gun” Four-Link Housing Brackets and 1/2" shock mounting holes.
“Top Gun” housing brackets, with or without shock
mounting provisions, are made from 1/4" thick mild Ladder Bar Housing Bracket
steel and drilled with 5/8" holes. Without Shock Mount
Part No. Description CCE3600-1
CCE3515-1 With Shock Mount, 8" x 12-1/4" Mild steel, 1/4" thick bracket
CCE3515-2 Without Shock Mount, 5-3/4" x 12-1/4"
includes 5/8" holes that are 7-1/8"
center-to-center.

“Top Gun” Four-Link Frame Bracket Wheelie Bar Bracket
CCE3505-5 CCE3620-1
Made from 1/4" mild steel with 5/8" holes and 23" radius. Made from 1/4" mild steel with 3/8" hole on 1.5" radius
and 9" center-to-center on mounting holes.

Tall “Top Gun” Four-Link Frame
Brackets
Tall brackets have 5/8" holes for 3/4" x 5/8"
moly rod ends to allow smaller incremental adjust-
ment.
Part No. Description
CCE3515-3 1/4" Mild Steel, 4" x 16", 5/8" Holes
CCE3515-3M 1/4" Chrome Moly, 4" x 16", 5/8" Holes
