2020 DRAG RACING

Adjustable Shock Mount Small Universal Tabs
Housing Bracket Tabs are 1" tall x 1-1/4" with 5/8" radius. Hole is 3/8".
CCE3714-4
Part No. Description
Replacement for the Chassis En gi neer ing weld-on ad just- CCE2893 0.090" Chrome Moly
able shock mount bracket. Made from 1/4" mild steel CCE3893 0.125" Mild Steel
with 3/8" holes and 3" diameter cut out.
Medium Size Tabs
Medium tab is 1-1/2" tall x 1-1/4" wide with a 5/8"
Bolt-On Shock Mount Brackets
radius and 3/8" hole.
Replacement bolt-on bracket for Chassis En gi- Part No. Description
neer ing CCE3714 ad just able shock mounts. CCE2895 0.090" Chrome Moly
Part No. Description CCE3895 0.125" Mild Steel
CCE3714-2 Right Bolt-On Shock Mount Bracket
CCE3714-3 Left Bolt-On Shock Mount Bracket Large Chassis Tabs
Large chassis tabs have a 1/2" hole.
Lower Shock Mount Bracket
Part No. Description
CCE3714-5
CCE2908 0.125" Chrome Moly
Replacement bracket for Ford 9" housings with 2" CCE3908 0.1875" Mild Steel
x 3" back brace. Made from 1/4" mild steel with
3/8" holes. Universal Tab
CCE3913
Universal tab is manufactured from 3/16" thick mild steel
and has a single 1/2" hole.
Rear Shock Mount
Parachute Tabs
CCE3717-1
3/16" mild steel bracket is 3" tall x 2-1/2" Tabs are 1-3/4" tall x 1-3/4" wide, .125" thick with
wide with 1/2" hole and 1-1/2" radius. 3/8" hole.
Part No. Description
CCE2892 0.125" Chrome Moly
CCE3892 0.125" Mild Steel

Universal Tab
Aluminum Door Latch/Parachute Handle
CCE3889
CCE3910
1/8" thick mild steel tab is for use on flat tube and has a
1/8" aluminum, 10" tall with 3/16" holes.
3/8" hole.
Crossmember Brace Tabs
Part No. Description
Transmission Crossmember Mount
CCE3620-3 3/16" Mild Steel With 5/16" Hole
CCE5100-1A CCE3620-4 1/8" Mild Steel With 5/16" Hole
Mild steel, 1/8" thick bracket has a 1-5/8" radius
and a pair of 7/16" slots for transmission mounting. Bellcrank Tab
CCE3901
Window Mount Tabs Mild steel tab is 1/8" thick with 3/8" hole.
CCE3911
Made from .070" mild steel, tabs are .900" tall with Gusseted Chassis Tab
3/16" hole. Sold in packs of 25. CCE3890A
Gusseted tab, constructed from 1/8" thick mild steel, is
Universal Frame Brackets designed to fit 1-1/2" tube. Tab is 1-5/8" tall x 1-1/2"
wide with 13/16" radius and has a 3/8" hole.
Brackets have 1/2" hole and are 2-1/2" high x
2" wide with 13/16" ra di us.
Part No. Description
CCE2902 0.125" Chrome Moly
CCE3900 0.1875" Mild Steel-No Notch
CCE3902 0.1875" Mild Steel

194
