Angle Finder And Level Standard Series 4-Link
COE5020 COE2017
Handy direct-read-out gauge is the perfect tool More adjustable than
for measuring pinion angle. It can also be used to traditional ladder bars.
find angles or level for tube bending, sheet metal work, or general repairs. Several holes allow quick,
Accurate to within 1/2 of 1°. Made of high-impact ABS plastic. easy adjustment. Kit includes
17-1/4" long, 1" OD x .156"
Driveshaft Loops threaded links, 3/16" thick stamped steel brackets, adjusting nuts, and
hardware. Rod ends are not included. Brackets are also available separately.
Required by NHRA and IHRA on any car COE3028
13.99 or quicker fitted with slicks, mild Related Components
COE3408
Four Link Chassis Bracket, Radiused, Each
steel construction driveshaft loops are COE3410 Four Link Chassis Brackets, Pair
specially contoured to fit the floor pan. Choose from universal or vehicle COE3412 Four Link Rear End Brackets, Pair
specific versions. Sold complete with required hardware for installation.
Magnum Series 4-Link Kit
Part No. Description
COE3028 Universal Bolt-On Driveshaft Loop COE2028
COE3160 2005-10 Ford Mustang GT Engineered for ultra-high horsepower
COE3161 Chrysler LX, Auto Transmission
COE3162 2009-Up Dodge Challenger SRT8, Standard Transmission drag race cars with 3" diameter axle
COE3174 2010-Up Chevy Camaro LS/LT/SS, Standard Transmission tubes, Magnum Series 4-Link Kit
offers full rear suspension adjust-
Competition Ladder Bars ment. Kit includes heavy-duty, 1/4"
COE2006 thick housing and frame brackets
Provides a solid connection with 5/8" mounting holes on a 21"
between the chassis and rear radius, chrome moly steel link tubes with threaded tube inserts, chrome
axle housing. Bars are 33-1/2" in moly rod ends, and required hardware. Housing brackets may also be
length and constructed of 1" OD x purchased separately, and include mounting holes for wheelie bars, sway
.156" wall DOM steel tubing, threaded for 3/4" rod ends and will fit most bars and shock absorbers. Welding required.
drag cars. Include ladder bars, rear end brackets, gussets, rod ends, front Related Components
rod end safety brace (NHRA/IHRA approved), and mounting hardware. COE3421 Magnum Series Front Bracket
COE3427* Magnum Series 4-Link Housing Bracket, Each
Related Components COE3429* Magnum Series 4-Link Housing Bracket, Each
COE2019 Ladder Bar Crossmember *Brackets COE3427 and COE3429 are designed to be used together, requiring (2) of each
COE3409 Ladder Bar 2" x 3" Crossmember Bracket part number.
COE6150 Replacement Rear Rod Ends
Diagonal Link
Ladder Link Eliminate side-to-side
COE2005 rear axle movement to keep tires from rubbing wheel wells and to get the
A dual pivoting lower link adjusts without car down the track in a straight line. Link fits between the front mounting
removing the bar. Pinion angle and chassis bracket of the ladder bar or four link and the rear housing bracket on the
pre-load are changed by loosening the jam opposite side. Compatible with ladder bars, ladder links, and standard four
nuts and rotating the link in the proper direction. Link is 33-1/2" long and links with 5/8" or 3/4" mounting holes. Offered in mild steel, bolt-on or
made of 1" dia. x .156" wall DOM steel tubing. Bars, brackets, gussets, rod chrome moly, weld-on versions.
ends, front rod end safety brace (NHRA/IHRA approved), and mounting Part No. Description
hardware are included. COE2031 Weld-On Diagonal Link, 1" x .065" Wall, Chrome Moly, Requires 5/8" Mounting Holes
COE2052 Bolt-On Diagonal Link, 3/4" x .156" Wall, Mild Steel, Requires 3/4" Mounting Holes
COE3422 Replacement Clevis Bracket, 5/8"
Chrome Moly Rod Ends COE3423 Replacement Clevis Bracket, 3/4"
Chrome moly is the best choice for four link or ladder bar
suspensions. Each rod end is sold complete with jam nut. Magnum Series Anti-Roll Bar
COE2027
Part No. Description Thread Shank & Hole Load Capacity
COE6130 Chrome Moly Rod End 3/4" RH 3/4" x 3/4" 28,090 lbs. Anti-Roll Bar provides straighter,
COE6131 Chrome Moly Rod End 3/4" LH 3/4" x 3/4" 28,090 lbs. cleaner launches with eliminated
COE6133 Chrome Moly Rod End 3/4" RH 3/4" x 1/2" 23,256 lbs.
COE6154 Chrome Moly Rod End 3/4" RH 3/4" x 5/8" 23,256 lbs. body roll for improved 60' times.
COE6155 Chrome Moly Rod End 3/4" LH 3/4" x 5/8" 23,256 lbs. Kit includes 4130 steel chrome
COE6160 Extra Heavy Duty Chrome Moly Rod End 3/4" RH 3/4" x 5/8" 40,590 lbs. moly torsion tube, adjustable splined billet aluminum arms, adjustable links
COE6161 Extra Heavy Duty Chrome Moly Rod End 3/4" LH 3/4" x 5/8" 40,590 lbs.
with rod ends, mounting bracket, and necessary hardware for installation.
Welding required.
