2020 DRAG RACING

Command Center Cross-Over Delay Box
DEDCC3 DEDCO2
The Command Center combines the The CO-2 has the
functions of a delay box, RPM- same features
activated switch and two separate as the RTD-7, but
4-stage timers into a single unit. Unit allows the racer
also features four different delay modes including “cross talk”, “crossover”, to leave off op-
“interface”, and “run delay”. “Starting line control” provides an adjust- ponent’s light instead of waiting for his light when running against a car with a
able release time to increase throttle prior to launch, while “super start” slower ET. The CO-2 is compatible with 12-and 16-volt systems.
allows activating a starting line controller prior to staging. A lighted keypad
with raised numbers and lighted LED display help provide easy operation. Shift Timer
Compact unit is just 9.12" long x 3.75" tall x 2.13" deep for easy mounting. DEDST1
Sold with complete instructions.
Single-stage timer activates
CO2 or electric shifters by
Thunder Delay Box
time instead of RPM for
DEDT1
more consistency. Compact,
New, billet encased delay box easily mounted timer is
features a 250% larger display adjustable from 0-9.99 and may be activated with release of the trans-
for easier viewing, day or night. brake or line-lock.
Compact 6-7/8" W x 4" H x 1-1/2" D unit includes a lighted keypad and
display with scroll and cursor keys for quick, easy setting. Select from RPM Switch
four different delay modes including cross-talk, crossover, interface, and DEDRPM2
delay. Box additionally has skip up/skip down, remote dial-in board output, Unit uses electronic ignition to sense
independent line lock output, adjustable transbrake lockout, crossover com- RPM for activation of shift lights,
pensation, trip protection, and pro/full tree features. NHRA/IHRA approved shifters and other devices. Built-in
for all “box” classes.
delay prevents unwanted shifts due to
tire spin or converter flash. Push button
Lightning Delay Boxes
thumbwheels select shift points in 100 RPM increments to 9,900.
Made of billet aluminum, multi-
function delay boxes have modes Remote Display
for crossover, interface, delay, and DEDRD1
crosstalk. Starting line control with adjustable Equally suited to dragsters or
time release, “super start” automatic starting doorslammers, Remote Dis-
line control, two four-stage timers, lighted keypad, adjustable transbrake play displays dial-in in super
lockout, scroll-up or -down, remote display dial-in board output, lateness bright, 4" tall LED read out, putting an end to incorrect dial-ins. Lightweight
timer, and cross-over compensation are among the many other features. clear anodized aluminum housed unit uses a “no glare” lens, while the
NHRA-approved units are compatible with 12-or 16-volt systems and built-in sun sensor adjusts brightness and automatically dims the display
virtually any ignition. Lightning Plus unit includes all of the features of the at night. Requires a signal from Command Center (CC3), Bracket Master
standard Lightning but is slightly larger with a 250% larger display. (BM2), or Manual Control (MC1) to display dial-in.
Part No. Description
DEDL1 Lightning Delay Box, 3" x 6" Dashboard Cutout
DEDL2 Lightning Plus Delay Box, 3" x 7-1/2" Dashboard Cutout Multiple Relay Center
DEDMRC1
Reaction Time Delay Box Multiple Relay Center features
DEDRTD7 individually fused relays with
The RTD-7 Reaction Time Delay LED's for both inputs and
works with all ignition systems outputs, easing troubleshoot-
including magnetos, is 12-and ing. Unit simplifies the wiring
16-volt compatible and requires of relays for nitrous systems, fuel pumps, water pumps, fans, etc. Four
no batteries. Four push-button relays are ganged together to power up to four stages of nitrous, while a
thumbwheels allow selection of any delay up to 9.999 seconds. A full separate relay is isolated.
12 volts are supplied to the trans-brake, with no voltage drop through
the delay box. The 30-amp capability will easily handle any trans-brake
manufactured.
