Hyper-Cool Remote In-Line Fan Thermostats
Oil Coolers A clean, simple method to activate the fans
Highly effi cient stack plate coolers incorpo- found on Hyper-Cool, Atomic-Cool or Electra-
rate built-in Tornado reversible electric fans for Cool remote oil coolers. Unit threads into the
superior fl uid cooling. Coolers include anodized AN inlet of cooler, activates the fan at 180°F, DER13021
aluminum shrouds and -6, -8, -10, or -12 ports. and turns it off at 170°F. Kit includes hose barb adapters for
Choose from standard Hyper-Cool, Hyper-Cool Dual or Hyper-Cool Extreme coolers with barb fi ttings. Standard series are non-clockable and include
assemblies separately, or in kit form complete with 180° in-line thermo- barb fi ttings, while Premium series are anodized fi nished and clockable.
stat, 10' OEM-spec. hose, hose clamps, fi ttings and mounting hardware. Part No. Description
DER13021 Standard Series, -6AN, 3/8" Hose
Description Dimensions Cooler/Fan Only Complete Kit
Hyper-Cool (25 Row Stacked Plate Cooler) DER15721 Standard Series, -8AN, 1/2" Hose
DER35020 Premium Series, -6AN/-6AN
Single Fan, -6 Ports 13" W x 10" H x 5-5/8" D DER13760 DER13960 DER35021 Premium Series, -8AN/-8AN
Single Fan, -8 Ports 13" W x 10" H x 5-5/8" D DER15860 DER15960 DER35022 Premium Series, -10AN/-10AN
Single Fan, -10 Ports 13" W x 10" H x 5-5/8" D DER15865 —
Hyper-Cool Dual (19 Row Stacked Plate Cooler) Single Powerpack
Dual Fan, -6 Ports 13" W x 7-7/16" H x 4-7/8" D DER13740 — Electric Fans
Dual Fan, -8 Ports 13" W x 7-7/16" H x 4-7/8" D DER15840 — High-output single electric fan assemblies are
Hyper-Cool Extreme (40 Row Stacked Plate Cooler) fi tted to aircraft-quality aluminum fan shrouds
Single Fan, -12 Ports 13" W x 14-7/8" H x 5-5/8" D DER15876 —
for maximum cooling effi ciency. Designed for
engine side mounting with built-in top and
Atomic-Cool Remote Oil Coolers
side mounts, fans are set-up as pullers. Satin
Atomic-Cool provides the largest temperature fi nished shrouds may be polished, painted, or anodized as desired.
drop of any fan-mounted cooler and may be Part No. Fan Size CFM Amp Draw Dimensions
used as an engine or transmission oil cooler. DER16820 14" 2,100 22 20" W x 16-3/8" H x 1-1/8" D
“Radiator-style” fi n and plate design and 8" DER16827 14" 2,100 22 23-7/16" W x 15-7/16" H x 1-1/8" D
dia., 400 CFM Tornado fan create maximum DER16818 17" 2,400 23.4 18" W x 18" H x 1-1/8" D
heat dissipation. Coolers are 10" tall x 12-1/2" DER16823 17" 2,400 23.4 21" W x 16-3/4" . x 1-1/8" D
24" W x 17" H x 1-1/8" D
DER16828
2,400
17"
23.4
wide x 4" thick and have -6AN or -8AN inlets.
Coolers include fan and mounting brackets. Kits add a fan thermostat, 10' Dual Powerpack
hose, adapter fi tting, and hardware. Electric Fans
Description Cooler/Fan Only Complete Kit Designed for applications with maximum
Atomic-Cool Remote Oil Cooler, -6AN Inlets DER13750 DER13950 cooling demands, Dual Powerpack Electric
Atomic-Cool Remote Oil Cooler, -8AN Inlets DER15850 DER15950
Fans are fi t with aircraft quality aluminum
Electra-Cool Remote Oil Coolers fan shrouds. Assemblies are designed for engine
side mounting with fans set-up in puller confi guration. Natural fi nish
Electra-Cool combines a cooler and a 10" dia.,
650 CFM Tornado electric fan for increased shrouds, which include top and side mounts for eased installation, may be
cooling effi ciency. Tube and fi n-style coolers painted, polished, or anodized as desired.
Dimensions
Part No.
CFM
are 10" tall x 12-1/2" wide x 4" thick and DER16833 Fan Size 3,750 Amp Draw 24" W x 17" H x 4-1/2" D
11"
37.4
have -6AN or -8AN inlets. Coolers include fan DER16835 11" 3,750 37.4 23-3/4" W x 19-3/4" H x 4-1/2" D
and mounting brackets. Kits include fan control DER16825 12" 4,000 49.6 25-5/8" W x 15-1/8" H x 4" D
thermostat, 10' hose, adapter fi ttings, and DER16826 12" 4,000 49.6 25-5/8" W x 17-1/8" H x 4" D
hardware. DER16836 12" 4,000 49.6 26-3/8" W x 16" H x 4" D
12"
4,000
27" W x 18" H x 4" D
49.6
DER16837
Description Cooler/Fan Only Complete Kit. DER16838 12" 4,000 49.6 28-1/4" W x 17" H x 4" D
Electra-Cool Remote Oil Cooler, -6AN Inlets DER13700 DER13900 DER16842 12" 4,000 49.6 26" W x 18" H x 4" D
Electra-Cool Remote Oil Cooler, -8AN Inlets DER15800 DER15900
Filter Mounts
Mounting Rod Kits
Ideal when a remote fi lter mount is desired, cast
Mount most electric fans or transmission coolers to any aluminum mounts accept popular Fram PH8A, HP1,
radiator. or equivalent. Offered with NPT or AN ports.
Part No. Description Part No. Description
DER13001 Insta-Mount Kit, 4 Plastic Rods, Pads And Retainers DER25708 Standard Filter Mount, 1/2"NPT Ports, Up Top
DER16743 Metal Rod Mounting Kit, 8 Metal Rods, Clips And Pads DER25709 Standard Filter Mount, 1/2"NPT Ports, Left/Right
DER16744 Nylon Mounting Kit, 4 Plastic Rods, Clips And Pads DER35708 Premium Filter Mount, -10AN/7/8"-14 Ports, Up Top
DER35709 Premium Filter Mount, -10AN/7/8"-14 Ports, Left/Right
