Page 29 - 2020-2021 Racecar Engineering Drag Racing Parts and Accessories Catalog

2020 DRAG RACING

Electrical, Gauges & Ignition

Primary Wire Terminal Connectors
Single-conductor stranded copper wire with polyvinyl in- Crimp-style connectors work great when building custom wire harnesses or
sulation which remains flexible and is abrasion resistant. making repairs to existing wiring. Tin-plated copper terminals are available
Stranded copper is the wire of choice for many projects in a variety of types and sizes.
when building custom wire harnesses or adding accessories.
Non-Insulated Terminals
20AWG
Used for low-voltage sensors, indicator lights, instrument panel, or dash lighting.
Color 50' Coil 100' Spool
Red ALL76500 ALL76510 Non-insulated terminals are designed to be crimped but may also be
Black ALL76501 ALL76511
White ALL76502 ALL76512 soldered for a more secure complete connection. Often used with separate
Green ALL76503 ALL76513 heat shrink that is applied after connection is made. Package of 20.
Yellow ALL76504 ALL76514 Non-Insulated Terminals 22-18 16-14 12-10
Brown ALL76505 ALL76515 Butt Connectors ALL76000 ALL76010 ALL76020
Blue ALL76506 ALL76516
#6 Hole ALL76001 ALL76011 ALL76021
#8 Hole ALL76002 ALL76012 ALL76022
14AWG #10 Hole ALL76003 ALL76013 ALL76023
Most popular when fabricating harnesses for general use including lighting of Ring Terminals 1/4" Hole ALL76004 ALL76014 ALL76024
headlights, taillights, and brake lights, ignition systems, and interior acces- 5/16" Hole ALL76005 ALL76015 ALL76025
ALL76026
3/8" Hole
ALL76006
ALL76016
sories such as radios, interior fans, and gauge panels. Male .250" ALL76007 ALL76017 ALL76027
Blade Terminals
Color 20' Coil 100' Spool Female .250" ALL76008 ALL76018 ALL76028
Red ALL76540 ALL76550
Black ALL76541 ALL76551 Vinyl Insulated Terminals
White ALL76542 ALL76552
Green ALL76543 ALL76553
Yellow ALL76544 ALL76554
Brown ALL76545 ALL76555
Blue ALL76546 ALL76556
Vinyl-insulated terminals are the most popular crimp terminal used in a
12AWG variety of applications. PVC insulated sleeve is securely attached to terminal
Wire can be used to supply power to ignition boxes, cooling fans, fuel pumps and has a flared end for easy installation. Package of 20.
and other higher amperage accessories including power to electric trailer Vinyl Insulated Terminals 22-18 16-14 12-10
brakes. Butt Connectors #6 Hole ALL76030 ALL76040 ALL76050
ALL76031
ALL76041
ALL76051
Color 12' Coil 100' Spool #8 Hole ALL76032 ALL76042 ALL76052
Red ALL76560 ALL76565 #10 Hole ALL76033 ALL76043 ALL76053
Black ALL76561 ALL76566 Ring Terminals 1/4" Hole ALL76034 ALL76044 ALL76054
White ALL76562 ALL76567 5/16" Hole ALL76035 ALL76045 ALL76055
Blue ALL76563 ALL76568 3/8" Hole ALL76036 ALL76046 ALL76056
Male .250" ALL76037 ALL76047 ALL76057
Blade Terminals
10AWG Female .250" ALL76038 ALL76048 ALL76058
Commonly used for higher amperage applications including alternator charg-
ing wire and supplying power to trailer for interior lighting or charging trailer Heat Shrink Terminals
batteries when utilizing tow vehicle charging system.
Color 10' Coil 75' Spool
Red ALL76570 ALL76575
Black ALL76571 ALL76576 Heat-shrink terminals protect connections from corrosion. Terminals with
White ALL76572 ALL76577
attached shrink tube are adhesive lined to grip wire insulation and conform
Heat Sleeve to crimp when heated, sealing out moisture. Package of 10.
12-10
22-18
16-14
Heat Shrink Terminals
High-temperature silicone coated fiberglass sleeving is ALL34284 Butt Connectors ALL76060 ALL76070 ALL76080
non-flammable and resists temperatures up to 500°F. An excellent choice #6 Hole ALL76061 ALL76071 ALL76081
for protection of fuel lines, wiring, cables, and various similar uses. Sleeving #8 Hole ALL76062 ALL76072 ALL76082
is resistant to gasoline and many other chemicals. Sold in 3 ft. lengths. Size Ring Terminals #10 Hole ALL76063 ALL76073 ALL76083
1/4" Hole
referenced is sleeve I.D., or O.D. of hose to be covered. 5/16" Hole ALL76064 ALL76074 ALL76084
ALL76075
ALL76065
ALL76085
Part No. Description Part No. Description 3/8" Hole ALL76066 ALL76076 ALL76086
ALL34280 1/4" Red ALL34290 1/4" Black Blade Terminals Male .250" ALL76067 ALL76077 ALL76087
ALL34282 1/2" Red ALL34292 1/2" Black Female .250" ALL76068 ALL76078 ALL76088
ALL34284 3/4" Red ALL34294 3/4" Black
ALL34285 7/8" Red ALL34295 7/8" Black
ALL34286 1" Red ALL34296 1" Black
28
