2020 DRAG RACING

Mini Alternators Digital Mini Shift Light And Diagnostic Tachometer
Ideally suited to the racer desiring a lightweight, reliable PFM67007C
single-wire alternator. Mini 96mm alternators weigh just Digital mini shift sight aids performing timely,
6 lbs. and offer 50 amps of charging. Manufactured consistent shifts by illuminating at a pre-set
from 100% all-new components. Sold complete with RPM. Compact unit is just 4-1/4" long and
V-belt pulley. may be adjusted from 100-12,000 RPM
Part No. Description in 100 RPM increments. May be quickly
PFM66432 Mini Alternator, Black Crinkle Finish removed from mount and set on dashboard, allowing RPM’s to be viewed
PFM66433 Mini Alternator, Polished Finish
during engine diagnosis.
Chevrolet High-Torque Mini Starters
Adjustable RPM Shift Lights
100% new starters are offset for oil pan clearance
and may be rotated for header or oil pan clearance. Get the desired shift points without a tachometer
High-torque motors deliver 40-50% more cranking or RPM modules. May be set from 3,000 to
power than stock starters. Features include 3.75:1 gear 12,000 RPM.
reduction, full ball bearing construction and shims to set Black Silver
Description Part No. Part No.
pinion gear engagement (when necessary). Adjustable RPM Shift Light PFM67005C PFM67005SC
Part No. Description
PFM66256 153/168T Flywheel, 1.4 KW, Up To 11:1 Comp. Locking Transmission Dipsticks
PFM66258 153/168T Flywheel, 2.0 KW, Up To 15:1 Comp.
PFM66266 168T Flywheel, Staggered Bolt Pattern, 1.4 KW, Up To 11:1 Comp. Mandated by NHRA on any car quicker than
PFM66267 168T Flywheel, Staggered Bolt Pattern, 2.2 KW, Up To 15:1 Comp. 10.99 E.T., dipstick assem-
PFM66268 168T Flywheel, Staggered Bolt Pattern, 1.4 KW, Up To 10:1 Comp. blies include a locking design
GM LS1/LS2/LS6/LS7 Starter, 153/168T Flywheel,
PFM66273 to prevent fluid from blowing out of dipstick tube. Offered with gold iridite
1.4 KW, Up To 11:1 Compression NEW!
GM LS1/LS2/LS6/LS7 Starter, 153/168T Flywheel, or chrome-plated finish.
PFM66277
2.2 KW, Up To 15:1 Compression NEW!
Gold Chrome
Description Part No. Part No.
Chevrolet High-Compression Racing Starters GM TH-350 PFM66181 PFM66175
GM TH-400
For engines with large displacement or high compres- GM Powerglide, Long Style For Door Cars PFM66182 PFM66178
—
PFM66172
sion ratios. Gear reduction starters have 100% new GM Powerglide, Short Style For Dragsters PFM66173 —
components. 4.4:1 ratio is capable of cranking engines
with up to 18:1 compression ratios. Perfect Launch Aluminum Rear End Covers
Part No. Description Reinforced aluminum rear end covers incorporate
PFM67050 68-Tooth Flywheel/Flexplate special load bolts to stabilize the carrier bearing
PFM67051 53-Tooth Flywheel/Flexplate
PFM67052 168-Tooth Flywheel/Flexplate, Staggered Mt. caps during launch, helping to prolong differential
life and eliminate failure. Black painted covers
feature both fill and drain plugs, and are sold
Chrysler High-Torque Starters
complete with required fasteners. Choose from
Lightweight high-torque starters fit all Chrysler covers with Perfect Launch or Bowtie logo.
V6 and V8. Choose from standard or officially Perfect Launch Logo Bowtie Logo
licensed Mopar units. Description Part No. Part No.
Dana 60 PFM69504 —
Part No. Description
Ford 8.8”
—
PFM440-415 Officially Licensed Starter, 4.41:1 Ratio, 11:1 Max. Compression GM 7.5” 10-Bolt PFM69501 PFM141-695
PFM66667
PFM66269 Chrysler Starter, 4.41:1 Ratio, 11:1 Max. Compression
GM 8.5” 10-Bolt PFM66668 PFM141-696
GM 8-7/8” 12-Bolt PFM69502 PFM141-697
Ford High-Torque Starters
High-torque, gear-reduction starters are lightweight Perfect Launch Drag Racing Practice Tree
and compact, yet offer 40-50% more cranking PFM67025C
power than OEM units. Offset design offers increased Practice reaction times anywhere with pocket-
oil pan clearance and rotating design allows for added chas- sized Perfect Launch. Powered by a 9-volt battery,
sis or header clearance. Starters are 100% new, not rebuilt. hand held unit includes a remote thumb trigger,
Part No. Description .400 and .500-second pro and full trees, adjust-
PFM66275 Ford Starter, 221-351W, 429-460, Auto Trans., 2.2 KW, Up To 15:1 Comp. able delay, bump down, and roll out.
Ford Starter, 221-351W, 429-460,
PFM66276
Manual Trans., 2.2 KW, Up To 15:1 Comp.

550
