Page 566 - 2020-2021 Racecar Engineering Drag Racing Parts and Accessories Catalog

2020 DRAG RACING

Ignition Control Panels Extreme Ignition Control Panel
QRP50-7164
QuickCar’s high-current, specially wound copper wiring performs superbly Extreme ignition panel combines the
and the high-temperature insulation is impervious to acids, oils, and fuels. benefits of precise waterproof micro
Extra-thick (.040") connectors are crimped and soldered for superior tensile switches with built-in fuse access and
strength (15,000 PSI) and all connections are insulated with shrink tubing. a compact, 7" x 3-1/4" size. Panel
24k gold-plated connectors improve current transfer and resistance to oxida- includes momentary start, ignition, and
tion. Panels are offered in checkered flag or black, and come pre-wired and five accessory switches. Completely pre-wired and ready to install.
ready to install.

Ignition Control Panels With Rocker Switches
QRP50-163 (Checkered Flag)
QRP50-863 (Black)
Similar in quality and construction to traditional QuickCar ICP's, but with
Includes ignition switch, momentary premium rocker switches. Panels feature 25 amp capacity switches that are
starter button, and five fused accessory dust/water resistant and include screw-on terminal connections. Offered
switches. Measures 7" wide x 3-1/4" high. in checkered flag or black, panels are pre-wired and ready to install. May
be plugged in directly to QRP50-200 or QRP50-201 wiring harnesses, if
QRP50-164 (Checkered Flag) desired.
QRP50-864 (Black)
Includes ignition switch, momentary QRP52-165 (Checkered Flag)
starter button , five fused accessory QRP52-865 (Black)
switches with pilot lights. Measures 7" Includes ignition switch, momentary
wide x 4" high. starter switch, and three accessory
switches. Measures 7" wide x 3" high.
QRP50-165 (Checkered Flag)
QRP50-865 (Black) QRP52-166 (Checkered Flag)
Includes ignition switch, momentary QRP52-866 (Black)
starter button, and five accessory switches. Measures 7" wide x 2" high. Similar to above, but with lighted rocker
switches. Includes ignition switch, momentary starter switch, and three
QRP50-166 (Checkered Flag accessory switches. Measures 7" wide x 3" high.
QRP50-866 (Black)
Includes ignition switch, momentary QRP52-163 (Checkered Flag)
starter button, and five accessory QRP52-863 (Black)
switches with pilot lights. Measures 7" wide x 3-1/4" high. Similar to above, but with fused
rocker switches. Includes ignition switch,
Ignition Control Panels With Circuit Breakers momentary starter switch, and three
Attractive gloss black Ignition control panels accessory switches. Measures 7" wide x 3-1/2" high.
include premium 20-amp circuit breakers for
the ultimate in electrical system protection. Accessory Switch Panel
Circuit breakers utilize an easy, resettable QRP52-164 (Checkered Flag)
design. Panels are completely pre-wired and QRP52-864 (Black/Lighted)
ready to install. Top-of-the-line panel includes both fused
Part No. Description and lighted rocker switches. Includes
Similar To The Above Panel, But 1” Taller To Accommodate
QRP50-869 ignition switch, momentary starter switch and three accessory switches.
The Addition Of Six Pilot Lights. Measures 6-7/8” Wide x 5” Tall.
Measures 7" wide x 3-1/2" high.
Replacement Resettable Circuit Breakers QRP52-716
May be reset with the touch of a button. Offered QRP52-716 (Black) NEW!
in various amp ratings, heavy-duty circuit breakers QRP52-717 (Black) NEW!
include screw connectors to ensure positive con- Suited to applications that may include
nections. existing ignition/starter switches but
Part No. Description require an additional accessory panel. Panels are 5-3/4” wide x 3” tall,
QRP50-9715 15 Amp include four accessory switches, and are offered in lighted or non-lighted
QRP50-9720 20 Amp
QRP50-9725 25 Amp versions.
QRP50-9730 30 Amp

565
