2020 DRAG RACING

Front Steering Brace For GM F-Body Super Lube Chassis Lubricant
Tubular steel brace Able to withstand temperatures from -45° to 450°F, multi-
bolts directly under purpose Super Lube has been found to be the best synthetic
the OEM front sway bar of 1983-92 GM F-bBody (Camaro/Firebird), joining grease currently available. Super Lube aerosol may be used to
the left and right front subframes for improved steering response and better protect rod ends from rust and corrosion.
handling. Constructed from 1-1/4” DOM mild steel, steering brace is offered Part No. Description
with black or red powder coated finish. UMI3008 Super Lube Synthetic Grease, 14-Oz. Tube
UMI3009 Super Lube Multi-Purpose Lubricant, 11-Oz. Aerosol Can
Black Red
Part No. Part No.
UMI2030-B UMI2030-R Transmission Mounted Torque Arm For GM F-Body
Tubular steel torque arm directly
Shock Tower Brace For GM F-Body replaces the OEM torque arm, elimi-
UMI2005-R nating wheel hop and improving traction. Adjustable version allows for
Shock tower brace precise pinion angle adjustment. Torque arms fit all 1982-02 GM F-Body
joins the left and (Camaro/Firebird), and are fully compatible with GM 10-bolt, Moser, and
right front shock towers, improving front suspension rigidity and aiding Strange 12-bolts, and most 9” rears.
steering response. Featuring a red powder coated finish, brace fits popular Black Red
1993-02 Camaro and Firebird. Description Part No. Part No.
Transmission Mounted Adjustable Torque Arm UMI2205-B UMI2205-R
Transmission Mounted Torque Arm — UMI2206-R
Subframe Connectors For GM F-Body Note: 1982-84 models require purchase of a 1985-up clamshell mount.
Subframe connectors
tie the front and rear Torque Arm Replacement Bushing
subframes together, UMI3004
improving chassis rigidity Replacement front torque arm bushing for 1982-02 GM
for enhanced traction F-Body (Camaro/Firebird) using OEM-style mount.
and better handling.
Tubular connectors for
1993-02 F-Body, offered in 2-point bolt-in or 3-point weld-in versions, Torque Arm Relocation Kit For GM F-Body
are constructed from 1-3/4” diameter DOM mild steel. Weld-in subframe Special transmission crossmember with an integrated torque
connectors for 1982-92 F-Body utilize a boxed, 2” x 1-1/4” design. Offered arm mount allows installing a TH-350 transmission into any
with black or red powder coated finish. 1982-92 GM F-Body (Camaro/Firebird), while maintaining
Black Red connection to the OEM-style torque arm. Kit requires no
Description Part No. Part No. drilling or welding and is compatible with virtually any stock
Tubular Subframe Connectors, 2-Pt. Bolt-On, UMI2002-B* UMI2002-R* or aftermarket-style torque arm.
1993-2002 F-Body
Black Red
Tubular Subframe Connectors, 3-Pt. Weld-On, — UMI2004-R* Part No. Part No.
1993-2002 F-Body
UMI2230-B UMI2230-R
Boxed Subframe Connectors, Weld-On, UMI2400-B UMI2400-R
1982-1992 GM F-Body
* Will not fit convertibles. Torque Arm Hardware Kits
UMI3003
Tunnel Brace Mounted Torque Arm For GM F-Body Recommended when bolting an aftermarket torque arm
UMI2202-R to the OEM rear end or similar rear ends that use a long
Heavy-duty replace- through-bolt design. Kit fits 1982-02 GM F-Body (Camaro/
ment torque arm for Firebird), and includes longer 9/16” Grade 8 bolts to accommodate the
the 1993-02 GM thicker torque arm mounting plates.
F-Body (Camaro/ Note: Kit will not work with Moser 12-bolt rears. Use UMI2998 for Moser 12-bolt rears.
Firebird) adds chassis
rigidity and eliminates suspension flex, while relocating the torque arm Rear Shock Relocation Kit For GM F-Body
mounting point off of the transmission tailhousing to prevent possible UMI2047
transmission damage. Tunnel-mounted torque arm bolts to existing floor Specialized kit for 1982-02 GM F-Body
pan holes using 3/16" laser cut mounting plates and metric 10.9 hardware. (Camaro/Firebird) relocates the OEM rear
Red powder coat finished. shock absorber to a double shear mount,
eliminating binding. Drilling is required. Sold complete with required
hardware.
