2020 DRAG RACING

Tubular Rear Lower Control Arms & Tubular Upper And Lower Control Arm Kits
Panhard Bar Kits For GM F-Body For GM G-Body
All-in-one, direct bolt-on kit Rigid tubular steel control arms directly
replaces the OEM stamped replace the OEM stamped steel units,
steel rear lower control arms eliminating bushing deflection and wheel
and Panhard bar on popular hop, while increasing traction and chassis integrity. Control arms fit all
1982-02 GM F-Body (Camaro/Firebird) with heavy-duty tubular steel 1978-88 GM G-Body (Malibu/Monte Carlo/Cutlass/Regal/Lemans/Grand
improving traction and preventing wheel hop. Components are constructed Prix), and are fabricated from 1-5/8” x .120” wall DOM mild steel tubing
from seamless DOM mild steel tubing and fit with greasable polyurethane and fitted with greasable polyurethane bushings. Kit includes one pair of
bushings. Kits are available with standard or adjustable control arms and upper and one pair of lower control arms with choice of black or red powder
Panhard bars in black or red powder coated finish. Components are also coated finish. Upper or lower control arms may be purchased separately.
offered separately. Black Red
Description Part No. Part No.
Black Red
Description Part No. Part No. Tubular Upper And Lower Control Arms Kit UMI301516-B UMI301516-R
Lower Control Arms And Panhard Bar Kit UMI201520-B UMI201520-R Related Components
Lower Control Arms And Adj. Panhard Bar Kit UMI201529-B UMI201529-R Tubular Lower Control Arms UMI3015-B —
Related Components Tubular Lower Control Arms, Single Adjustable UMI3014-B —
Lower Control Arms UMI2015-B UMI2015-R
Panhard Bar, Single Adjustable — UMI2019-R Rear Coil-Over Kits For GM G-Body NEW!
Panhard Bar Relocation Kit UMI2024-B — True bolt-on rear coil-over kits for
Panhard Bar, On-Car Adjustable UMI2029-B UMI2029-R
Panhard Bar Lowering Bracket UMI2063-B* — 1978-88 GM G-Body applications
Panhard Bar Relocation/Conversion Kit UMI2064† — using the OEM rear end housing,
* Designed for use with UMI2024 to prevent Panhard bar interference on lowered vehicles. † Converts feature a multi-position design to
UMI2024 to UMI2062.
allow fine tuning of ride height
Aluminum Body Mounts For GM F-Body and shock location. Race-proven
UMI2664 NEW! lower bracket joins the OEM lower
Rigid precision-machined aluminum mounts trailing arm mounting location with the lower shock absorber attachment
point. Choose from kits that use the stock or multi-position control arm
directly replace the OEM rubber mounts on attachment points. Kits are also available complete with Viking 19-way
1970-81 Camaro/Firebird, restoring body loca- adjustable shock absorbers and 2-1/2" ID, 14" tall coil-over springs. Each
tion and reducing subframe movement. Black kit includes necessary hardware and instructions.
anodized mounts are sold complete with necessary hardware.
Part No. Description
Brackets-Only Rear Coil-Over Kits
Frame Repair Kits
For GM A-Body & F-Body UMI3048 GM G-Body Rear Coil-Over Bracket Kit, Control Arm Relocation
UMI3049 GM G-Body Rear Coil-Over Bracket Kit
A do-it-yourself kit used for repairing the Complete Rear Coil-Over Kits
frame of popular GM A-Body and F-Body With Brackets, Shock Absorbers And Coil-Over Springs
cars. Kits provide a rigid surface with UMI3049-110 GM G-Body Rear Coil-Over Kit, 2"-3" Lowering, Drag Race/Street Applications
properly-sized holes to restore the frame UMI3064-110 GM G-Body Rear Coil-Over Kit, Stock Height (1" Lower To 2" Above)
correctly. Cutting and welding is required. Note: Coil-over brackets are designed to fit factory rear ends only. Rear shocks may not clear
Part No. Description all exhaust tail pipes.
UMI2662-B Front Subframe Repair Kit, 1970-81 F-Body (Camaro/Firebird)
UMI4055 Frame Repair Kit, 1964-72 GM A-Body (Skylark/Chevelle/Cutlass/Lemans) Rear Shock Tower Brace
For GM A-Body & G-Body
Front Reinforcement Brace For GM G-Body
Precise jig-built built brace ties the rear upper shock mounts together,
Engineered specifically for the 1978-88 GM strengthening the rear chassis. Brace is manufactured from 1-1/4” mild
G-Body (Malibu/Monte Carlo/Regal/ steel tubing with laser cut and MIG-welded 3/16” mounting brackets. Of-
Cutlass/Grand Prix/Lemans), front fered with black or red powder coated finish.
frame brace reinforces Black Red
and strengthens the front Description Part No. Part No.
frame horns and crossmember area. Fabricated from 1-1/4” steel tubing 1978-88 G-Body UMI3055-B UMI3055-R
with 3/16” laser-cut mounting brackets, direct bolt-on brace is offered with 1968-72 A-Body UMI4058-B UMI4058-R
black or red powder coated finish. 1964-67 A-Body UMI4059-B UMI4059-R
Black Red
Part No. Part No.
UMI3053-B UMI3053-R

675
