2020 DRAG RACING

Racing Oil Filters Oil Filter Adapters
Wix racing oil filters utilize “glass-enhanced” When exhaust header-to-oil filter
cellulose media, which enhances their ability clearance is an issue, specialized
to capture particles as small as 10-12 microns, adapters convert engine mounted
removing up to 94% more dirt than traditional filter to a remote mounted base.
filters. Many filters include built-in bypasses to maintain Adapters include 1/2" NPT female inlet and outlet ports. Oil lines must be
oil pressure even under heavily clogged conditions. purchased separately.
Thread Filter Filter Media Flow Bypass Anti-Drain Part No. Description
Part No. Application Size Height Dia. Type Rate Setting Back Valve WIX24730 Oil Filter Adapter, 3/4"-16 Threads (Ford/Chrysler)
WIX51060R Chevy 13/16"-16 5.17" 3.6" T-71 28 None Yes WIX24734 Oil Filter Adapter, 13/16"-16 Threads (GM)
WIX51061R Chevy 13/16"-16 5.17" 3.6" T-71 28 None No
WIX51069R Chevy 13/16"-16 4.33" 3.6" T-71 28 None No Racing Air Filters
18-22
WIX51222R Remote Mount 1-1/2"-12 6.21" 4.6" T-71 28 No
PSI Racing air filter elements flow over 1,000 CFM without compromising
WIX51268R Remote Mount 1-1/8"-16 5.21" 3.6" Paper 30 None No filtering qualities. The Wix racing air filters remove dirt, debris, and other
8-11
WIX51515R Chrysler/Ford 3/4"-16 5.17" 3.6" T-71 28 Yes contaminants before they enters the engine, providing extended piston ring
PSI
WIX51794R Chevy 13/16"-16 7.82" 3.6" T-71 28 None No life.
18-22
WIX57003R Remote Mount 1-1/2"-12 6.21" 4.6" T-10 30 No Part No. Description
PSI
18-22 WIX46945R 14" Dia. x 3" Tall
WIX57007R Remote Mount 1-1/2"-16 5.9" 4.2" T-10 30 No
PSI WIX46926R 14" Dia. x 3.25" Tall
WIX46948R 14" Dia. x 3.5" Tall
Chevy Spin-On Oil Filter Conversion Kit
WIX46927R 14" Dia. x 3.75" Tall
WIX24061
WIX46944R 14" Dia. x 4" Tall
Popular mount is used to convert 1956-67 WIX46974R 16" Dia. x 3" Tall
Chevy V-8 from OEM canister-type to spin-on WIX46949R 16" Dia. x 3.5" Tall
oil filter. Includes base, gasket, mounting WIX46940R 16" Dia. x 4" Tall
bolts, and instructions.
Replacement Fuel Filter
Remote Mount Oil Filter Mounting Base WIX33900R
Typically used in conjunction with an oil filter Paper element is a direct replacement
adapter, remote-mounted base may be used to for the Fram HPGC1.
filter engine oil, transmission fluid, etc. Oil filter
base includes three mounting holes, dual 1/2"
NPT inlet and outlet ports, and two 1/2" NPT
plugs for blocking off unused ports.
Part No. Description
WIX24764 Remote Mounted Base, Accepts 3/4"-16 Filters (Ford/Chrysler)
WIX24766 Remote Mounting Base, Accepts 13/16"-16 Filters (GM)

Photo by: Ashley Kindle Steve Town Photo by: Ashley Kindle Larry Stoker
