2020 DRAG RACING

NEW VENDOR!

Manual Tube and Pipe Bender Throatless Rotary Shear
WWFWFB2 WWFWFMS
Manually-operated unit can effectively bend up to Bench-top shear may be used to cut virtually any shape out
2" round or square tubing. Metal-framed bender of metal up to 1/8" thick. Forged steel-framed unit
uses CNC-machined components, engraved degree combines a ratcheting head, adjustable cutter, and
ring, and 36" handle for smooth, precise operation. adjustable work stop to aid performing precise cuts.
Optional stand converts unit from bench-top to
stand-alone operation. Manual tube bender dies BOSS 16-Gauge Box and Pan Brake
may be purchased separately. WWFWFBOSS16
Part No. Description The BOSS is capable of making
WWFWFB2STAND Optional 37" Tall Stand For WFB2 precise bends to up to 1/16" (20 gauge)
WWFWFBDT11/2X5 1-1/2" Round OD Tube Die x 5" CLR 120° Die Set mild steel. Box and pan brake uses rigid
WWFWFBDT11/2X5-180 1-1/2" Round OD Tube Die x 5" CLR 180° Die Set fingers, heavy trusses, braces and bronze
WWFWFBDT11/4X4 1-1/4" Round OD Tube Die x 4" CLR 120° Die Set
WWFWFBDT11/4X4-180 1-1/4" Round OD Tube Die x 3" CLR 180° Die Set bearings at the pivot points to eliminate
WWFWFBDT13/4X6 1-3/4" Round OD Tube Die x 6" CLR 120° Die Set deflection. Unit uses removable 2", 3" and
WWFWFBDT13/4X6-180 1-3/4" Round OD Tube Die x 6" CLR 180° Die Set 4" fingers, and includes a bend angle stop that
WWFWFBDT15/8X5 1-5/8" Round OD Tube Die x 5" CLR 120° Die Set may be set from 0°-130°. Brake is 48-1/4" long and is sold complete with
WWFWFBDT15/8X5-180 1-5/8" Round OD Tube Die x 5" CLR 180° Die Set heavy duty floor stand.
Pipe Notcher 24" x 20-Gauge Box and Pan Brake
WWFWFN6 WWFWFBP2420
Engineered for use with any 1/2" hand Bench-top box and pan brake is 24"
drill, tool mounts to a bench or clamps in long and includes five removable 1",
a vise and can notch tubing from 3/4" to 2", 3", 8", and 10" fingers, capable of
3" OD Notcher includes solid steel construction with a hardened and ground bending up to 1/16" (20-gauge) mild
spindle, and accepts standard hole saws. steel.

3-In-1 48" x 16-Gauge Box and Pan Brake
Bend-Roll-Shear Machines WWFWFBP4816
Versatile bench-top units are capable Popular 48" long unit features
of bending, rolling, or shearing up to heavy-duty construction with a
20-gauge mild steel. Offered in 12" or 30" reinforced frame and is capable
long versions, units use 1-1/2" diameter of bending up to 16-gauge mild
solid steel rollers, while removable fingers steel. Box and pan brake uses 16 hardened and ground fingers (5-2", 5-4",
are used for box and pan bending. and 6-3").
Part No. Description
WWFSP3-1-12 12" Long Bend-Roll-Shear Machine 24" Power Bead Roller
WWFSP3-1-3 30" Long Bend-Roll-Shear Machine
WWFWFBR24P
Throatless Hand Shears Variable-speed bead roller has an 18-gauge capacity, and is
Offered in 8", 10", or 12" long versions, hand shears powered by a 1/4 HP gear drive motor and uses a conve-
utilize a throatless design that allows cutting up to 3/16" nient foot pedal control. Unit has a 24" throat depth and
steel or 3/8" round bars. Heavy steel-framed units use is operable in forward or reverse. Sold complete
an arched top blade that allows virtually effortless cutting with floor stand, die rack for convenient storage,
throughout the entire stroke. and 1/2" round bead die.
Part No. Description
WWFSPHS8 8" Throatless Hand Shear English Wheel
WWFSPHS10 10" Throatless Hand Shear WWFWFEW-2
WWFSPHS12 12" Throatless Hand Shear Designed for the forming of up to 1/16" mild steel, English
Wheel uses a large, 8" top wheel, quick release lower anvil
and 28" throat depth. 60" tall unit is constructed using a
heavy-duty boxed frame complete with floor stand. Sold
complete with 6-piece radius anvil set (2-3/8", 3", 5", 8-1/2", and 12").
