2020 DRAG RACING

Stainless Steel Braided CPE Race Hose
Stainless steel outer braid delivers durability, heat-resistance and great looks. The elastomer chlorinated polyethylene (CPE) inner tube is compatible with a
wide range of liquids.
Size ID OD 3 Feet 6 Feet 10 Feet 15 Feet 20 Feet
-6 .344" .547" XRP300306 XRP300606 XRP301006 XRP301506 XRP302006
-8 .438" .641" XRP300308 XRP300608 XRP301008 XRP301508 XRP302008
-10 .562" .797" XRP300310 XRP300610 XRP301010 XRP301510 XRP302010
-12 .688" .928" XRP300312 XRP300612 XRP301012 XRP301512 XRP302012

Aluminum Hose Ends Aluminum Push-On Hose Ends
XRP hose ends are aviation nipple and cutter-style to prevent blow-off and Machined from aluminum alloy with red and blue or black anodized finish,
leakage problems. Fittings are built from heat-treated aluminum and are hose ends are only compatible with push-on hose, NOT stainless steel
race ready. braided hose. All hose ends are JIC 37°. See pg. 723 for hose clamps and
Red/Blue Black Red/Blue pliers.
Swivel Swivel Non-Swivel
Black
Part No. Part No. Part No. Size Red/Blue Part No. Size
Part No.
Straight Straight
XRP100004 XRP100004BB — -4 XRP230004 XRP230004BB -4
XRP100006 XRP100006BB — -6 XRP230006 XRP230006BB -6
XRP100008 XRP100008BB — -8 XRP230008 XRP230008BB -8
XRP100010 XRP100010BB — -10 XRP230010 XRP230010BB -10
XRP100012 XRP100012BB — -12 XRP230012 XRP230012BB -12
XRP100016 XRP100016BB — -16 45°
— XRP100020BB — -20 XRP234504 XRP234504BB -4
30° Hose Ends XRP234506 XRP234506BB -6
XRP203006 XRP203006BB — -6 XRP234508 XRP234508BB -8
XRP203008 — XRP103008 -8 XRP234510 XRP234510BB -10
XRP203010 XRP203010BB — -10 XRP234512 XRP234512BB -12
XRP203012 XRP203012BB — -12 60°
XRP203016 XRP203016BB — -16 XRP236006 XRP236006BB -6
45° Hose Ends — XRP236008BB -8
— — XRP104504 -4 — XRP236010BB -10
XRP204506 XRP204506BB XRP104506 -6 XRP236012 XRP236012BB -12
XRP204508 XRP204508BB XRP104508 -8 90°
XRP204510 XRP204510BB XRP104510 -10 XRP239004 XRP239004BB -4
XRP204512 XRP204512BB XRP104512 -12 XRP239006 XRP239006BB -6
XRP204516 XRP204516BB XRP104516 -16 XRP239008 XRP239008BB -8
60° Hose Ends XRP239010 XRP239010BB -10
XRP206006 XRP206006BB — -6 XRP239012 XRP239012BB -12
— XRP206008BB — -8 120°
XRP206010 XRP206010BB — -10 XRP231204 — -4
XRP206012 XRP206012BB — -12 XRP231206 XRP231206BB -6
90° Hose Ends XRP231208 XRP231208BB -8
— — XRP109004 -4 XRP231210 XRP231210BB -10
XRP209006 XRP209006BB XRP109006 -6 XRP231212 XRP231212BB -12
XRP209008 XRP209008BB XRP109008 -8 150°
XRP209010 XRP209010BB XRP109010 -10 XRP231506 XRP231506BB -6
XRP209012 XRP209012BB XRP109012 -12 XRP231508 — -8
XRP209016 XRP209016BB XRP109016 -16 XRP231510 — -10
— — XRP109020 -20 XRP231512 XRP231512BB -12
120° Hose Ends 180°
— — XRP112004 -4 XRP231806 — -6
XRP212006 XRP212006BB XRP112006 -6 XRP231808 XRP231808BB -8
XRP212010 XRP212010BB XRP112010 -10 XRP231812 — -12
XRP212012 XRP212012BB — -12
— XRP212016BB — -16
150° Hose Ends
— — XRP115006 -6 Double Swivel Forged 90° Hose Ends
XRP215010 — — -10 Red/Blue Black
XRP215012 XRP215012BB — -12 Part No. Part No. Size
180° Hose Ends XRP209106 — -6
— — XRP118004 -4
XRP218006 XRP218006BB XRP118006 -6 XRP209108 XRP209108BB -8
XRP218008 XRP218008BB — -8 XRP209110 XRP209110BB -10
XRP218010 XRP218010BB XRP118010 -10 XRP209112 XRP209112BB -12
XRP218012 XRP218012BB — -12 Note: Double swivel-style ends are triple sealed and adjustable after assembly to hose. All
XRP218016 — — -16 hose ends are JIC 37°.
