Page 261 - 2018 Racecar Engineering Open Wheel Parts and Accessories Catalog

Chassis Components (Cont.)
Drivetrain Components
Tubular Steel Driveshaft MWADS-30H Midget Steering Components MWAPA-15
M&W Aluminum offers a complete line of Midget steering compo-
nents and suspension parts. Lightweight, yet durable, all compo-
Lightweight, yet exceptionally strong, tubular 4340 steel driveshaft nents listed are manufactured from premium, 2024 aluminum.
is 30" long. Part No. Description
MWAPA-15 Pitman Arm, 15" Long
Engine Components MWAPA-15-A Pitman Arm,
Throttle Linkage And Arms MWAMID-SA3 15" Long With 10° Offset
Single Steering Arm
Right Rear Torsion Arm,
MWAMID-RRTA-12.5-2.5
2-1/2" Offset
MWAMID-LRTA-14 Left Rear Torsion Arm
MWAMID-CSA-3L Combo Steering Arm
MWAMID-TS-175 1-3/4" Aluminum Torsion Stop MWAMID-SA3
MWAMID-WB-3 Wishbone

Midget Birdcages
MWAMID-BC-200
MWATLK-1E Engineered exclusively for use
Part No. Description on popular Midgets, M&W’s Bird-
MWATH-312 Throttle Arm, 5/16" cages are fully CNC-machined
MWATH-375 Throttle Arm, 3/8" from durable, 6061 billet aluminum
MWATLK-1E Throttle Linkage Kit, Eagle and incorporate an adjustable design.
Sold in pairs, left birdcage includes
a single row bearing, while right unit features a double row bearing.
Chassis Components Inserts are also available for left and right birdcages. Sold as a pair.
Sprint Car Birdcage Bearings Part No. Description
Part No. Description Replacement Components
MWA6014-2RS Birdcage Bearing MWAMID-BCI-1 Single (Left) Bearing Birdcage Insert For 31 Spline Axles
MWA6214-2RS Large Birdcage Bearing MWAMID-BCI-2 Double (Right) Bearing Birdcage Insert
For 31 Spline Axles
MWA5011-2RS Birdcage Bearing Double Row For Midget Cages
13-1/2" Tubular MWA6011-2RS Birdcage Single Row Bearing For Midget Cages
Jacobs Ladder
MWATJL-13.5-CHPC
Rear Sprockets
Mini/Micro Sprint rear sprockets are
manufactured from 7075-T6 aluminum.
Front Wing Posts MWAFWP-200-3/OS-POL Available in 5.25" or 6.43" bolt circle.
Uses a 520 chain.
MWAFWP-100-POL Part No. Description Part No. Description
5.25" Bolt Circle 6.43" Bolt Circle
MWASP520-525-35T Rear Sprocket 35T MWASP520-643-40T Rear Sprocket 40T
Part No. Description
MWASP520-525-36T Rear Sprocket 36T MWASP520-643-41T Rear Sprocket 41T
MWAFWP-100-POL Front Wing Post, Straight, 1"
MWAFWP-200-3/OS-POL Front Wing Post, Bent, 1" MWASP520-525-37T Rear Sprocket 37T MWASP520-643-42T Rear Sprocket 42T
MWASP520-525-38T Rear Sprocket 38T MWASP520-643-43T Rear Sprocket 43T
MWASP520-525-39T Rear Sprocket 39T MWASP520-643-44T Rear Sprocket 44T
MWASP520-525-40T Rear Sprocket 40T MWASP520-643-45T Rear Sprocket 45T
Aluminum Shock Pin Kit MWASP520-525-41T Rear Sprocket 41T MWASP520-643-46T Rear Sprocket 46T
MWASP520-525-42T Rear Sprocket 42T MWASP520-643-47T Rear Sprocket 47T
MWASHP-100-KIT MWASP520-525-43T Rear Sprocket 43T MWASP520-643-48T Rear Sprocket 48T
Fits Maxium and Triple XXX cars. MWASP520-525-44T Rear Sprocket 44T MWASP520-643-49T Rear Sprocket 49T
MWASP520-525-45T Rear Sprocket 45T MWASP520-643-50T Rear Sprocket 50T
MWASP520-525-46T Rear Sprocket 46T MWASP520-643-51T Rear Sprocket 51T
MWASP520-525-47T Rear Sprocket 47T MWASP520-643-52T Rear Sprocket 52T
MWASP520-525-48T Rear Sprocket 48T MWASP520-643-53T Rear Sprocket 53T
MWASP520-525-49T Rear Sprocket 49T MWASP520-643-54T Rear Sprocket 54T
Aluminum Jam Nuts MWASP520-525-50T Rear Sprocket 50T MWASP520-643-55T Rear Sprocket 55T
MWASP520-525-51T Rear Sprocket 51T MWASP520-643-56T Rear Sprocket 56T
Part No. Description
MWASP520-525-52T Rear Sprocket 52T MWASP520-643-57T Rear Sprocket 57T
MWAAJN-10L 5/8" ID x 3/4" OD, Left Hand MWASP520-525-53T Rear Sprocket 53T MWASP520-643-58T Rear Sprocket 58T
MWAAJN-10R 5/8" ID x 3/4" OD, Right Hand MWASP520-525-54T Rear Sprocket 54T
MWASP520-525-55T Rear Sprocket 55T
MWASP520-525-56T Rear Sprocket 56T
MWASP520-525-57T Rear Sprocket 57T
MWASP520-525-58T Rear Sprocket 58T
260
