Page 264 - 2018 Racecar Engineering Open Wheel Parts and Accessories Catalog

Quarter Midget Steering Wheel
Sprint Car/Dirt Midget Aluminum, 11" diameter steering wheel is
among the lightest available for popular Quarter
Steering Wheel MPIMPI-D-15-A Midgets. Spokes are slotted for maximum
This 15" diameter three slotted spoke zero weight reduction. Wheel is covered with Lederfylon, a high grip syn-
dish aluminum wheel features a polyurethane thetic material that is hand sewn with orange stitching and topped
grip with extended padding on the spokes. with an embroidered MPI logo. Choose from traditional round or
Orange centering mark. Three hole mounting. square steering wheels, which provide improved vision.
Part No. Description
MPIMPI-KQR-11-A Round Steering Wheel
Racer Steering Wheels Square Steering Wheel,
MPIMPI-KQS-11-A
These new low priced black aluminum Improved Visibility And Ergonomics
steering wheels are available in both fl at and
dished versions. Featuring a polyurethane Karting/Quarter Midget/
grip with extended padding on the three slot-
ted spokes. Three hole mounting. Mini-Outlaw Oval Steering Wheel
Part No. Size The aluminum steering wheel features a fl at
MPIMPI-DR-15 15" Flat top and bottom for improved visibility and
MPIMPI-DR-16 16" Flat ergonomics. The three spokes are slotted to
MPIMPI-DR-17 17" Flat reduce weight and the wheel is covered with
MPIMPI-DMR-15 15" Dished Lederfylon, a high grip synthetic material that
MPIMPI-DMR-16 16" Dished is hand sewn with orange stitching. Orange
MPIMPI-DMR-17 17" Dished centering marks. Three hole mounting. Dish
1/2". Weight: 1 pound.
Dirt Karting D-Shaped Steering Wheel Part No. Description
MPIMPI-KD-14-A MPIMPI-KP-12-A 12" Diameter
13" Diameter
MPIMPI-KP-13-A
The aluminum 14" diameter steering wheel
features a fl at top for improved visibility. The
three spokes are slotted to reduce weight and Center Pad MPIMPI-A-CP-D
the wheel is covered with Lederfylon, a high For Sprint And Kart Wheels.
grip synthetic material that is hand sewn with
orange stitching. Orange centering marks. Steering Wheel Suede Brush
Three hole mounting. 2" dish. Weight: 1 Lb.
MPIMPI-A-SB
Steering Wheel Cover Steel brush to maintain steering wheel
suede.
MPIMPI-A-SWC
Protects the steering wheel during transport
at the track and around the shop. Double Paddle Shifter
MPIMPI-A-PS
For sim racing. Can be used with MPIMPI-RS-LG. Fits all mpi 3 and
6 bolt wheels. Recommended for iracing.

NexTek Series Oval Track Valve Springs 10° Titanium Retainers
Put an end to spring degradation. NexTek springs are Manley’s 6AL 4V titanium 10°
specially processed from chrome silicon that undergoes retainers have the durability
winding, thermal treating and fi nishing processes prior to needed for racing engines. Sold
shipment. Spring ID is fully chamfered for retainer clear- in sets of 16.
ance. Sold in sets of 16. Dimensions
Spring
Max. Seat Open Coil Part No. Type Height Spring O.D. A B C D
Part No. Application OD/ID Valve Lift Pressure Pressure Bind MAN23640-16 Double +.100" 1.625" 1.500" 1.175" .850" —
MAN221445P-16 † Oval Track, 1.620"/.852" .800" 280@ 680@ 1.200" MAN23644-16 Double Std. 1.550" 1.500" 1.140" .740" —
Roller 2.050" 1.250" MAN23648-16 Double +.100" 1.580"/1.610" 1.500" 1.150" .825" —
Roller, w/o 250@ 750@
MAN221452SF-16* 1.550"/.800" .825" 1.150" MAN23650-16 Double +.100" 1.550" 1.500" 1.140" .740" —
Damper 2.025" 1.200" MAN23654-16 Double Std. 1.625" 1.500" 1.175" .765" —
* Signifies Super Finished. † Signifies polished finish. MAN23655-16 Double +.100" 1.625" 1.500" 1.175" .765" —
MAN23658-16 Double Std. 1.550" 1.500" 1.105" .710" —
MAN23661-16 Double +.100" 1.550" 1.500" 1.120" .705" —

263
