Page 286 - 2018 Racecar Engineering Open Wheel Parts and Accessories Catalog

Intake Manifold Gaskets Advance And Retard Cam Bushings
Mr. Gasket offers three different Kit includes four offset bushings for advance
types of Intake Manifold Gaskets: and retard, plus a 0° bushing so stock timing
traditional Mr. Gasket cellulose/ can be used again. Cam sprocket dowel pin
nitrile material, Ultra-Seal cellulose/nitrile material with silicone hole must be drilled.
beading around each port, and new Super intake gaskets, which Part No. Description
seal quickly during assembly, release easily during disassembly and MRG85 283-454 Chevy, 0°, 2°, 4°, 6°, 8°
require no gasket sealer.
MRG85B 283-454 Chevy, 0°, 1°, 3°, 5°, 7°
Application Port Dim. Thk. Mr. Gasket Ultra-Seal
Chevy Small Block 262-400
Small Race Port 1.25" x 2.13" 1/16" — MRG5821 Precision Timing Tape
Medium Race Port 1.31" x 2.19" 1/16" MRG102G MRG5822 Avoid the expense of degreeing the harmonic bal-
Medium Race Port 1.31" x 2.19" 1/8" MRG116 MRG5812
Large Race Port 1.31" x 2.31" 1/16" MRG111 MRG5823 ancer. Mr. Gasket’s timing tape is accurately calibrated
Large Race Port 1.31" x 2.31" 1/8" MRG113 MRG5813 and perfect for timing engines or setting valve lash for
X-Large Race Port 1.38" x 2.38" 1/16" — MRG5824 increased performance.
Brodix Aluminum 1.38" x 2.25" 1/16" — — Part No. Description
18° Roll Over 1.35" x 2.26" 1/16" MRG143 — Chevrolet
MRG1588 6-3/4" Dia. 283-400 cu. in.
Exhaust Manifold/Header Gaskets 8" Dia. 1970-73, 396-427-454 cu. in. 1965-68, 327 cu. in.
MRG1591
Ultra-Seal Hi-Performance 1970-73, 350 cu. in.
MRG1592 6" Dia. 1957-73 283-350 Cu. In.
Copper Seal
Aluminum Competition Wire Separators
MRG9728
Mr. Gasket Heat-resistant, black plastic wire
Traditional Mr. Gasket exhaust gaskets are a high temperature separators minimize cross firing
acrylic blend – exceptional sealing and durability. Ultra-Seal exhaust and fit 7mm and 8mm plug
gaskets are high temperature steel core/graphite faced material for wires. Includes two each:
added durability. Copper Seal gaskets are dead soft .043" thick em- 2-wire clips, 3-wire clips and 4-wire clips.
bossed copper that will never blow-out and may be used over and
over. New aluminum gaskets will not shrink, deteriorate or blow-out.
Application Port Dim. Mr. Gasket Ultra Seal Copper Seal Aluminum Grommet Set MRG3706
Chevrolet Small Block 262-400 Assortment of 30 grommets are useful when
1955-91 1.45" x 1.55" MRG150A MRG5901 MRG7153 — running wires, cables or hoses through sheet
Medium Square Port metal. Includes six grommets each in 1/2",
1955-91 Small 5/8", 3/4", 7/8" and 1" sizes.
Square Port 1.45" x 1.48" MRG150C MRG5900 MRG7151 MRG7401G
Round Port 1.50" Dia. MRG150B MRG5907 MRG7150 — MRG6120
Round Port 1.63" Dia. MRG150 MRG5902 MRG7152G MRG7402G
Brodix “D” Degree Wheels MRG1570
Shaped Port 1.55" x 1.71" — MRG5903 — —
Brodix 1.65" x 1.60" — MRG5906 — — Degree camshafts just like
Spread Port a professional. Affordable, 7"
Oval Port diameter universal degree
Header Flange 1.50" x 1.82" — MRG5917 — — wheel is ideal for degreeing
cam in car, or while the en-
gine is on a stand. Large, 11"
Timing Cover Seals And Gaskets
diameter Pro Degree Wheel
Part No. Description is color-coded for maximum readability and unsurpassed accuracy
Timing Cover Seals MRG18 for degreeing on engine stand. Each wheel includes crankshaft bolt
MRG18 Metal Clad, Chevy Small Block, 1955-96 262-400 adapters.
Timing Cover Gaskets
MRG90 Cork/Rubber, Chevy Small Block, 1955-96 262-400 MRG92 Part No. Description
MRG92 Syntheseal, Chevy Small Block, 1955-96 262-400 MRG1570 Universal Degree Wheel, 7" Dia.
MRG93 Composite, Chevy Small Block, 1955-96 262-400 MRG6120 Pro Degree Wheel, 11" Dia.

Valve Cover Gaskets Engine Oil Primer MRG3795G
Mr. Gasket offers three types
of valve cover gaskets: tradi- Primer will pressurize the oiling system and lubricate bearing
tional, Mr. Gasket high density sur fac es before initial start-up. Use in an ordinary elec tric drill and
cork/rubber, steel core Ultra-Seal, and steel core molded rubber. insert in the distributor opening. Fits all V8 and 6 cylinder Chevys.
Application Thk. Mr. Gasket Ultra-Seal Molded Rubber
SB Chevy, 1958-86 265-400 3/16" MRG175 MRG5860 MRG5853G
SB Chevy, 1958-86 265-400 5/16" MRG179 MRG5861 — Magnetic Oil Pan Drain Plug
SB Chevy, 1958-86 265-400 1/4" — MRG5855 —
SB Chevy, 1986-96 305-350 3/16" MRG168 MRG5867 — Part No. Description
MRG15 Magnetic Oil Pan Drain Plug, 1/2"-20
MRG16 Replacement 1/2" Nylon Washer
285
