Page 288 - 2018 Racecar Engineering Open Wheel Parts and Accessories Catalog

Chevrolet Pro Mag 12LT Cylinder Markers
Designed for sprint car racing, unit is nearly 30% lighter MSD3414
and smaller for a better fit. Power producing generator Molded plastic markers ensure
clamps to the billet aluminum lower housing which allows that plug wires are always in the
easy timing changes. Magneto provides incredible power right place. Designed for 8.5mm wire.
and is maintenance-free (no points, batteries or magnets).
Sold with cap, rotor, bronze gear and connectors. An elec-
tronic points box is required. Pro-Heat Guard Wire Sleeve
Part No. Description MSD3411
MSD7908 Pro Mag 12LT
MSD79081 Pro Mag 12LT Short Base Provides extra protection to
MSD79082 Pro Mag 12LT Short Base, Black spark plug wires. Tough, glass-
MSD79083 Pro Mag 12LT, Black woven sleeving is covered with silicone rubber and resists up to
1,000°F. Sold in a 25 foot roll.

Pro-Clamp Wire Separators
Electronic Points Boxes
MSD8843
Part No. Description Snap together separators have special
Endurance, Events Over 50 Laps, MSD81063
MSD8106 grooves to hold wires firmly without dam-
With Rev Limiter, Red
MSD81063 Points Box 12 Amp Pro Mag, Black aging insulation. Kit includes two 4-wire
assemblies, two 3-wire assemblies, and
four 2-wire assemblies.
Pro Mag Replacement Parts
Made with DuPont Rynite high Pro-Crimp Tool MSD35051
dielectric material, cap features stain-
less terminals for maximum corrosion The ideal tool for making up a
resistance. quantity of plug wires, or doing
custom wiring. Pro-Crimp’s in-
Part No. Description
MSD7919 Cap and Rotor Kit Pro Mag LT, Red terchangeable jaws can form
MSD79193 Cap and Rotor Kit Pro Mag LT, Black a variety of different crimps
MSD7905 Mag Clamp For Pro Mags MSD79193 using one tool. Hardened
MSDMSD19735 Slip Collar For Mag steel frame, comfortable molded hand grips and ratchet action yield
MSD8471 Chevy Bronze Distributor Gear secure, factory quality crimps every time. Supplied with crimping/
MSD8148 Band Clamp stripping jaws for MSD spark plug wire terminals.
MSDMSD17193 Drive Brushing
Mini Stripper/Crimper MSD3503
Custom Fit Chevy An inexpensive way to make a set of custom made
Sprint Super Conductor plug wires. Die is used to strip Super Conductor wire.
Stripper/crimper can then be placed in a vise to provide
8.5mm Spark Plug Wire Sets a solid terminal crimp to the wire.
Super Conductor 8.5mm spark plug wire set is
cut to fit for “tight fit” Chevy V8 Sprint Cars.
Wires have 90° ends at both the spark plug Kill Switch And Harness MSD8111
and magneto cap, have extremely low resis-
tance, high RFI suppression and are specifically Heavy duty, single pole, single throw switch
for use with the Pro Mag. is rated at 15 Amps and is designed for the
Pro Mag 12.
Part No. Description NOTE: For use with 12 amp magnetos only, not for
MSD31543 8.5mm Spark Plug Wire Set, Black use with the Pro Mag 44.
MSD31549 8.5mm Spark Plug Wire Set, Red
Super Conductor Coil Wires Midget Accessories
Coil wires endure eight times the use of each
plug wire and should be replaced often.
Part No. Description
MSD84033 Black
MSD84039 Red MSD84033

MSD6214 MSD8240 MSD31689
Pro-Boot Guard MSD3412 Part No. Description
Protects spark plug boots from MSD6214 DIS-2 Programmable Ignition
excessive heat. Slide-on sleeve has MSD8240 Coil Pack
fiberglass woven inside coated with
silicone rubber to withstand extreme MSD31689 8.5 Spark Plug Wire Set
temperatures. Six foot roll.

287
