Page 315 - 2018 Racecar Engineering Open Wheel Parts and Accessories Catalog

“A” Series “AC” Series
Aluminum Smooth Body Shocks Aluminum Threaded Body Shocks
Twin tube, "A" Series smooth body shocks, suited for use on late The “AC” Series shock is made from a high-tech alu mi num impact
models, open wheels and modifieds, offer superior driver feel and ul- extrusion and ma chined to the highest of stan dards. Available in
timate traction. Fully rebuildable and revalvable, each shock is serial strokes from 5" to 9", thread ed-body shock eliminates the threaded
numbered, dyno tested and sold complete with dyno sheet. Shocks tube from the coil-over kit. Shocks include bearing ends. Simply
include bearing ends. Simply purchase PROC300 to convert these purchase PROC320 to convert these shocks to coil-over units.
shocks to coil over units.
Coil-Over Kits For ACF Series
Rebound Adjustable Shocks
Part No. Description
Pick the com pres sion damping shock number and turn Coil-Over Kit, 2-1/2",
the rebound adjuster (3-4-5-6-7-8 or 6-7-8-9-10-11) to the PROC352 Flat Spring Seat
corresponding number. Shocks have the same acceleration
ramps and blow-off curves as stan dard Pro Shocks. Avail- PROC353 Coil-Over Kit, 2-1/2",
Tapered Spring Seat
able in 7", 8" and 9" strokes.
7" 8" 9"
Stroke Stroke Stroke Compression Rebound Rebound Adjustable
— PROA836-11R PROA936-11R 3 6-11
PROA743-8R — PROA943-8R 4 3-8 Threaded Body Shocks
— PROA846-11R PROA946-11R 4 6-11 User-friendly Shocks can be ad-
PROA753-8R PROA853-8R PROA953-8R 5 3-8 justed by turning the rebound adjuster
from 3 to 8, 6 to 11 or 5 to 14. Shocks
have the same acceleration ramps
Aluminum Smooth Body Shocks and blow-off curves as stan dard Pro
Shocks. Avail able in 7" and 9" strokes.
Collapsed Extended Damping
Part No. Stroke Length Length Comp./Rebound 7" 9"
Stroke Stroke Compression Rebound
PROA640B 6" 11.50" 17.50" 4/4
PROA646B 6" 11.50" 17.50" 4/6 PROACF743-8R — 4 3-8
PROA650B 6" 11.50" 17.50" 5/5 — PROACF953-8R 5 3-8
PROA740B 7" 12.50" 19.50" 4/4 PROACF756-11R — 5 6-11
PROA745B 7" 12.50" 19.50" 4/4
PROA746B 7" 12.50" 19.50" 4/6
PROA750B 7" 12.50" 19.50" 5/5 “AC” Series
PROA751B 7" 12.50" 19.50" 5/1 Aluminum Threaded Body Shocks
PROA752B 7" 12.50" 19.50" 5/2
PROA754B 7" 12.50" 19.50" 5/4 Collapsed Extended Damping
PROA757B 7" 12.50" 19.50" 5/7 Part No. Stroke Length Length Comp./Rebound
PROA760B 7" 12.50" 19.50" 6/6 PROAC530B 5" 10.50" 15.50" 3/3
PROA762B 7" 12.50" 19.50" 6/2 PROAC550B 5" 10.50" 15.50" 5/5
PROA763B 7" 12.50" 19.50" 6/3 PROAC557B 5" 10.50" 15.50" 5/7
PROA764B 7" 12.50" 19.50" 6/4 PROAC730B 7" 12.50" 19.50" 3/3
PROA770B 7" 12.50" 19.50" 7/7
PROA791B 7" 12.50" 19.50" 9/1 PROAC740B 7" 12.50" 19.50" 4/4
PROA838B 8" 13.50" 21.50" 3/8 PROAC746B 7" 12.50" 19.50" 4/6
PROA846B 8" 13.50" 21.50" 4/6 PROAC750B 7" 12.50" 19.50" 5/5
PROA847B 8" 13.50" 21.50" 4/7 PROAC753B 7" 12.50" 19.50" 5/3
PROA848B 8" 13.50" 21.50" 4/8
PROA849B 8" 13.50" 21.50" 4/9 PROAC754B 7" 12.50" 19.50" 5/4
PROA850B 8" 13.50" 21.50" 5/5 PROAC757B 7" 12.50" 19.50" 5/7
PROA9310B 9" 14.50" 23.50" 3/10 PROAC760B 7" 12.50" 19.50" 6/6
PROA938B 9" 14.50" 23.50" 3/8 PROAC770B 7" 12.50" 19.50" 7/7
PROA939B 9" 14.50" 23.50" 3/9
PROA940B 9" 14.50" 23.50" 4/4 PROAC791B 7" 12.50" 19.50" 9/1
PROA945B 9" 14.50" 23.50" 4/5 PROAC935B 9" 14.50" 23.50" 3/5
PROA946B 9" 14.50" 23.50" 4/6 PROAC940B 9" 14.50" 23.50" 4/4
PROA947B 9" 14.50" 23.50" 4/7 PROAC946B 9" 14.50" 23.50" 4/6
PROA948B 9" 14.50" 23.50" 4/8
PROA950B 9" 14.50" 23.50" 5/5 PROAC950B 9" 14.50" 23.50" 5/5
PROA953B 9" 14.50" 23.50" 5/3
PROA956B 9" 14.50" 23.50" 5/6
PROA957B 9" 14.50" 23.50" 5/7
PROA960B 9" 14.50" 23.50" 6/6 Coil-Over Kit PROC320
Aluminum coil-over kit for 2" body
Coil-Over Kit PROC300 “AC” shocks. Includes upper spring
seat, threaded adjuster and pin.
Aluminum coil-over kit for reg u lar size
2" body “A” series coil over shocks.

314
