Page 403 - 2018 Racecar Engineering Open Wheel Parts and Accessories Catalog

MINI-SPRINT

Bumpers And Nerf Bars Rear End Components

TXR600-BN-0005
TXR600-BN-0001
TXR600-SU-K9000

TXR600-SU-0192-BLK
Part No. Description
TXR600-BN-0001 Nerf Bar, Right Hand, Stainless Steel
TXR600-BN-0002 Nerf Bar, Left Hand, Stainless Steel
TXR600-BN-0005 Rear Bumper, Stainless Steel
TXR600-BN-0010 Front Bumper, Stainless Steel
TXR600-SU-0181-BLK TXR600-SU-0017
TXR600-BN-0067 Front Bumper, Stacked TXR600-SU-0453
Part No. Description
TXR600-BK-0001 Rear Brake Rotor, Steel, Ultra Light
Radius Rods TXR600-SU-0019 Rear Brake Carrier
TXR600-BK-0002-BLK
With Bearings And Hardware, Black
Splined Bearing Spacer
TXR600-SU-0017
For Bird Cage, Double Bearing, 1-1/4"
Splined Bearing Spacer
TXR600-SU-0023-BLK TXR600-SU-0018
For Brake Carrier, Single Bearing, 5/8"
Description Aluminum Black
TXR600-SU-0101 Bare Rear Axle Tube, 52"
Front Radius Rod,
3/8" x 15-1/2" TXR600-SU-0019 TXR600-SU-0019-BLK TXR600-SU-0102 Axle Nut, Right Hand
TXR600-SU-0103 Axle Nut, Left Hand
Drag Link Radius Rod, TXR600-SU-0021 TXR600-SU-0021-BLK
3/8" x 14-1/2" TXR600-SU-0181-BLK Sprocket/Rotor Hub, 1/4"-28, Black
TXR600-SU-0192-BLK Bird Cage With Bearing, Left Hand, Black
Left Rear Radius Rod, TXR600-SU-0023 TXR600-SU-0023-BLK
7/16" x 20" TXR600-SU-0193-BLK Bird Cage With Bearing, Right Hand, Black
Right Rear Radius Rod, TXR600-SU-0200 Bearing For Brake Carrier
7/16" x 21" TXR600-SU-0024 TXR600-SU-0024-BLK TXR600-SU-0202 Rear Bird Cage Bearing
Brake Rod, Steel, TXR600-SU-0025 — TXR600-SU-0453 Rear Axle Spacer Kit, 11 Pieces
7/16" x 20" TXR600-SU-K9000 Complete Rear Axle Assy.
Tie Rod And Drag Links MCP 600 Micro Sprint
Part No. Description Left Front Brake Caliper
Tie Rods TXRMCP-650
TXR600-SU-0182 3/8" x 36-1/2", Steel Left front brake caliper. Simply the nicest
TXR600-SU-0182-BLK 3/8" x 36-1/2", Steel, Black left front caliper on the market today, preci-
Drag Links sion machined for a perfect fi t and extreme weight
TXR600-SU-0021 3/8" x 14-1/2", Steel savings.
TXR600-SU-0021-BLK 3/8" x 14-1/2", Steel, Black
MCP 600 Micro Sprint
TRIPLE X MINI SPRINT CHASSIS REQUIREMENTS Left Front Brake Bracket
Description Component Length TXR600-BK-0004
Radius Rods
Left Front 15-1/2" (3/8" Thread) Steel bracket attaches the MCP front caliper and Keizer front rotor
to the Triple X spindle.
Right Front (2) 15-1/2" (3/8" Thread)
Left Rear 20" (7/16" Thread)
Right Rear 21" (7/16" Thread) MCP 600 Micro Sprint
Steering Rods Left Front Brake Pad
Tie Rod 36-1/2" (3/8" Thread) TXRMCP554BN
Drag Link 14-1/2" (3/8" Thread
Panhard Rod 15-1/2" (3/8" Thread)
Brake Rod
Brake Rod 20" (7/16" Thread), Steel MCP 600 Micro Sprint
Master Cylinder TXRMCP-875
Torsion Stop TXR600-SU-0170 Cast aluminum, 7/8" bore master
cylinder is easy to use with the Triple X
adjustable pedal system. Assembly pro-
vides premium performance without
breaking the budget.
Torsion Bushing TXR600-CH-3001
Sold individually.
402
