Page 404 - 2018 Racecar Engineering Open Wheel Parts and Accessories Catalog

MINI-SPRINT

Front End Components Jacobs Ladder
TXR600-SU-0002
10-1/4" Jacobs Ladder is chrome plated with
TXR600-FA-0002 straps and jig built for quality and exact fi t.

TXR600-FA-0008
Hardware Kit
TXR600-FA-0010
TXR600-CH-2846
Part No. Description Kits includes all steel bolts and nuts to
TXR600-FA-0002 Front Axle Bare, Torsion Bar Style assemble car.
TXR600-FA-0003 Front Axle Bare, Coil Over Style
TXR600-FA-0007 King Pin With Clips, Sold Individually
TXR600-FA-0008 Spindle, Right Hand
TXR600-FA-0009 Spindle, Left Hand
TXR600-FA-0010 Steering Arm, Left Front Combo
TXR600-FA-0011 Steering Arm, Right Front Combo
TXR600-FA-0012 Front Splined Nut, Sold Individually Engine Components
TXR600-FE-0652 Thrust Bearing Shim, Sold Individually Part No. Description
TXR600-FE-0653 Thrust Bearing, Sold Individually TXR600-EG-0039 Battery Box
TXR600-EG-0043 Motor Adjuster With Ends
Steering Components
TXR600-EG-0039
Wing Tree And Mounts

TXR600-TW-0004 TXR600-TW-0002
TXR600-ST-1009
TXR600-ST-1008 TXR600-ST-0005 TXR600-TW-0025
Part No. Description Part No. Description
TXR600-ST-0002 Lower Steering Shaft, 20-3/4" TXR600-TW-0002 Top Wing Tree
TXR600-ST-0003 Upper Steering Shaft TXR600-TW-0004 Top Wing Post, Sold Individually
TXR600-ST-0004 Steering Box, Rack And Pinion Frame Mount TXR600-TW-0007 Top Wing Manual Slider
TXR600-ST-0005 Upper Steering Support Bracket
TXR600-ST-1008 Replacement Gear and Shaft TXR600-TW-0025 Front Nose Wing Post, Sold Individually
TXR600-ST-1009 Replacement Rack TXR600-TW-0031 Aero Nose Wing Strap, Sold Individually

Pedal, Clutch And Chain Components XB Axles And Spindles

TXR600-CH-2045
TXR600-FA-5783BLK
Part No. Description
TXR600-FA-8201 XB Spindle Tall Boss
TXR600-FA-8201BLK XB Spindle Tall Boss, Black
TXR600-FA-8514 Locknut For XB Spindles Only
TXR600-FA-5783 XB Front Axle Tall Boss Used Only with XB Spindles
TXR600-DL-0002 XB Front Axle Tall Boss Used Only with XB Spindles,
TXR600-FA-5783BLK
Black
TXR600-EG-0012
TXR600-DL-0055
Rock Screen TXR600-CH-1336
Part No. Description
Pedals And Clutch Components This black powder coated
TXR600-CH-2019 “XPRS” Throttle Pedal 22-3/4" wide x 8-1/2" high steel
TXR600-CH-2020 “XPRS” Brake Pedal screen is manufactured with 2"
TXR600-CH-2045 “XPRS” Brake And Throttle Pedal System wide slots. Using the Triple X
TXR600-EG-0007 Shift Lever screen clamp (TXR600-CH-0954) mounting to the roll cage uprights
TXR600-EG-0012 Clutch Lever of both Triple X Midget and 600 chassis is simple and easy.
TXR600-EG-0057 Shifter Rod, 4" Long Part No. Description
Chain Components Related Component
TXR600-DL-0001 Drive Chain, Gold Link TXR600-CH-0954 Clamp For Mini Sprint, 1-1/4" ID
TXR600-DL-0002 Drive Tensioner Kit
TXR600-DL-0003 Drive Tensioner, Wheel
TXR600-DL-0055 Master Link

403
