ENGINE Caster Wheel Kits Aluminum Sprint Motor Plates

Hard rubber wheel kits may be
mounted to Allstar engine cradles
ALL10130 thru ALL10159. Kits are also ALL38118 ALL38119
available with locking wheels, ideal
for storing spare engines in trailer. ALL38128 ALL38130
Standard duty kits feature 3/8" studs
and heavy duty models use 1/2"
studs. Four wheels per kit.
Front motor plates for SB Chevy are
ALL10162...... Std. Duty 3" Dia. Kit offered in one- and two-piece
ALL10163 ..... Std. Duty 3" Dia. With Locking Kit designs. One-piece versions mount
ALL10164 ..... Heavy Duty 3" Dia. Kit using the lower front mounting
ALL10165...... Heavy Duty 3" Dia. With Locking Kit holes. Two-piece sets use the
ALL10166 ..... Heavy Duty 5" Dia. Kit
lower front mount holes and
the water pump mounting ALL38145
holes. All plates have 19-1/2" center-to-center
SB/BB Chevy Economy Engine Cradle chassis mounting holes. ALL38128 and ALL38145 plates
ALL10171 come with bushings to allow for engine flex and help with
weight transfer.
Cradle is great for storing
or transporting engines Part No. Description Finish Thickness
safely. Designed to fit ALL38118 1-Piece Solid Plate Plain 3/8"
small and big block ALL38119 1-Piece Solid Plate Black 3/8"
Chevrolet engines, cradle ALL38128 1-Piece Plate With Bushings* Black 3/8"
is fully welded from 1" ALL38145 2-Piece Plate With Bushings † Black 3/8"
square tubing and powder ALL38130 Universal Mount Plain 1/4"
coated black. Cradle has *Has built-in mount for Saldana tank mount bracket OTMB-1.
provisions for mounting †Designed to work with ALL36092 and ALL36093 tank mounts.
our standard duty wheel kits with 3/8" wheel studs.
Sprint Engine Cradle
ALL10159
Cradle bolts to most
SB Chevy Two-Piece Engine Stand
stock type and
ALL10157 aftermarket SB Chevy
Two-piece engine stand blocks, including
constructed from 1" x 2" narrow pattern
steel tubing is specially lightweight and
designed to clear most standard bell housing bolt patterns. Slotted front
oversized dry sump mounts accept most frame width engine mounts.
oil pans with up to a Provisions for standard wheel kits are positioned to sup-
9" deep sump. Stand includes six port complete engines with attached radiators.
3/8" x 1" grade 5 bolts and accepts
wheel kits with 3/8" studs. Bellhousing Dowel Pins
Steel dowel pins are approximately
1/2" longer than stock pins and are
Motor Plates required when running an engine mid-plate, ALL38152
Motor plates are used rear motor mounts or an aftermarket bellhousing. These
to replace the front ALL38120 extended length pins also help with alignment when
motor mounts allowing relocation of the engine in installing an engine. Pins fit most GM blocks and are sold
the chassis, including lowering or when moving the engine in pairs.
back in the chassis. Plates prevent engine movement and ALL38150 ..... Solid Pins
reinforce the front suspension for better handling and ALL38152 ..... Hollow Pins
increased reaction times. Fabricated from 1/4" thick 6061-T6
aluminum, motor plates are often trimmed to fit the chassis or Engine Cover ALL26234
frame mounts. Plates are machined for a perfect fit to mount Water-repellent cover with
between the water pump and engine block. bottom draw string is perfect for
ALL38120 ..... SB Chevy 10" x 36" storage or transportation. 32"
ALL38124 ..... BB Chevy 12" x 36" long x 23" wide x 28" tall.
