Page 52 - 2019 Allstar Performance Parts and Equipment Catalog

CHASSIS Tubing End Caps Remote Starter Button

Shroud Kits
Steel end caps weld to the end or
inside of tubing to provide a clean
look, prevent sharp exposed edges Kit mounts a remote starter button
directly to chassis tubing. Kit includes a
and seal tubes to keep out dirt and shroud to help protect against acci-
debris. Caps are commonly used on dental activation, tab, and starter button. ALL60361
ends of bumpers, to fill existing holes in ALL60360 ..... Welded Kit
frames and as a flat gusset when butt joining ALL60361 ..... Un-welded Kit
sections of square or rectangular tubing. Package of 10.
Part No. Description Thickness Battery Boxes
Round End Caps Universal, lightweight steel bat-
ALL22280 7/8" O.D. .125"
ALL22285 1" O.D. .125" tery boxes may be welded or
ALL22281 1-1/4" O.D. .125" bolted to the frame. Boxes are avail-
ALL22286 1-3/8" O.D. .125" able in two sizes and include hold down hardware.
ALL22282 1-1/2" O.D. .125" ALL76100 ..... Full Size, 12" Wide x 7-1/4" Deep
ALL22283 1-5/8" O.D. .125"
ALL22287 1-11/16" O.D. .125" ALL76101 ..... Short Style, 10" Wide x 7-1/4" Deep
ALL22284 1-3/4" O.D. .125"
Square End Caps Bolt-On Battery Boxes
ALL22290 1" x 1" .085" Battery box has multiple 1/2"
ALL22291 1-1/2" x 1-1/2" .085"
ALL22292 2" x 2" .085" mounting holes to bolt box directly to
the frame rail, inner fender or firewall.
Rectangle End Cap
ALL22294 2" x 3" .085" Box can also be fastened to round tubing
using clamp-on ballast brackets. Constructed ALL76103
Gussets of 13 gauge steel, measures 11" wide x 7" deep
and includes 3/8" battery hold down hardware.
Gussets add support and
strength to tubing joints ALL76102 ..... Clear Zinc
when building roll cages or chassis mounts. Solid, one or ALL76103 ..... Black
three hole gussets are 1-7/8" tall x 1/8" thick. Reinforced
gussets are 2-1/8" tall x 1/8" thick with a rolled edge for Stainless Steel Drop-Out
added strength. Battery Box ALL76105
Description 10-Pack Part No. 100-Pack Part No. The perfect battery box where battery
Solid ALL22192 ALL22192-100 mounts under floor. Eases battery service
With One Hole ALL22194 ALL22194-100 and replacement. Box is 10-1/2" wide, 7" deep,
With Three Holes ALL22196 ALL22196-100 and 9-1/2" tall and will accept most standard batteries.
Wrap Around Gussets
Ground Stud ALL76147
Gussets fit 1.50" to 1.75" tubing and
can be used to join tubing from 70° to Steel ground stud welds to round tubing NEW!
110°. Wrap around gussets are 1/16" thick providing a secure location for mounting
and provide more support and rigidity than a negative battery cable. Weld stud directly to the
a standard flat gusset. Sold in packs of 10. chassis or create a secure ground wire location in
the foot box or engine compartment. Stud accepts
ALL22199 ............ 10-Pack battery cables with 3/8" ring terminals.
ALL22199-50 ....... 50-Pack
Upper Coil-Over
Rub Rail Flange ALL60023
Flanges are 3/16" thick and commonly Shock Mount Kit
used when building bolt-on style rub rails. ALL60230
Center hole accepts 1-1/4" tubing and has two 3/8" Weld-in kit provides a
mounting holes spaced 2-1/4" apart. Package of 4. mounting point for rear
coil-over shock mounts
Charging Post Bracket on tube, boxed or stock
ALL60064 frames with up to 48"
between frame rails.
Securely mount Allstar charging posts
on vehicles where battery is not easily acces- Great for drag racing
sible. Predrilled holes allow quick mounting to frame or and street applications, kit includes a 48" long, .120" wall
body. Double-D hole design positions posts close together, x 1-1/2" mild steel tube, reinforced mounting tabs, 2" x
but provides enough room for charging or jumper cable 3" end plates and 1/2" hardware.
clamps. Charging posts sold separately.
50 www.allstarperformance.com
