Page 56 - 2019 Allstar Performance Parts and Equipment Catalog

CHASSIS Panhard Bar/Third Link 5/8" Rod End Reducer Spacers

Reducer spacers fit into 5/8"
Brackets
Brackets have a built-in arch for
size for 1/2" hardware while
adjustment of the Panhard bar or third rod ends, reducing the hole
link angle without changing the length of also spacing the rod end
the arm. Brackets are 1/8" thick. Sold as away from chassis brackets. ALL18615 ALL18612
a pair. Standard spacers are 3/4" O.D. and flanged spacers have
1" O.D. flanges to help support rod end. Size referenced
ALL60162 ..... 6-Hole Brackets With 1/2" ALL60162 ALL60167
Holes ALL60163 indicates the amount of space between rod end pivot ball
ALL60163 ..... 6-Hole Brackets With 5/8" ALL60165 and chassis bracket. Package of 2.
Holes Standard Spacers
ALL60165 ..... 6-Hole Brackets With 3/4" Holes ALL18615 ...... Aluminum, 1/2"
ALL60167 ..... 5-Hole Brackets With 3/4" Holes ALL18617 ...... Aluminum, 1"
ALL18618...... Aluminum, 1-1/4" NEW!
Weld-On Panhard Bar Bracket ALL18619...... Aluminum, 1-3/4" NEW!
ALL60168 Flanged Spacers
Bracket is made from 1/4" steel and has six 3/4" ALL18611 ...... Aluminum, 1/4"
mount holes for Panhard bar. Measures 8-1/2" tall ALL18613 ...... Aluminum, 1/2"
by 2" wide. ALL18610 ..... Steel, 1/4"
ALL18612 ...... Steel, 1/2"
Track Bar Locator Brackets
Track bar locator brackets are an ideal bolt-on mounting Tapered Spacers
point for rod ends commonly found on Panhard bars, Length Steel Aluminum Length Steel Aluminum
track bars or rear axle housing track locators. For 1/2" I.D. 5/8" I.D.
use with 1/2" diameter rod ends. Available with 1/4" ALL18570 ALL18590 1/4" ALL18580 ALL18597
a 5/8" or 3/4"bracket mounting hole. 3/8" ALL18571 — 1/2" ALL18582 ALL18598
ALL60079 ..... 5/8" Hole, 1" Gap 1/2" ALL18572 ALL18592 3/4" ALL18584 ALL18599
ALL60089..... 3/4" Hole, 1-3/16" Gap 3/4" ALL18574 ALL18594 1" ALL18586 –
ALL60079 1" ALL18576 ALL18596 3/4" I.D.
Trailing Arm Brackets 1/2" ALL18587 –
3/4" ALL18588 –
Steel brackets can be used as front mount for leaf spring 1" ALL18589 –
or trailing arm. Assorted styles are available. Sold each.
Trailing Arm Bracket ALL60042
ALL60043
Weld-on bracket has a curved 3/4" slot so
5/8" slot, 3/16" thick, rear end remains square as the trailing arm
3-3/4" long.
is raised or lowered. Notched for 2" x 3"
ALL60044 square tubing. 1/4" thick.
3/4" slot, 3/16" thick,
3-3/4" long. Slider Boxes
Slider boxes weld to the chassis and provide
an adjustable mount for trailing arms, Panhard
ALL60045 bars and upper links. Boxes are constructed of
5/8" holes, 1/8" thick. .120" wall material and are 1-1/2" wide x 2-1/2"
deep x 6" tall with a 4" slot that provides 3" of
adjustment.
ALL60186 ..... 4" x 1/2" Slot
ALL60188 ..... 4" x 3/4" Slot

ALL60046 Slider Box Quick Adjust Kit
5/8" holes, 3/16" thick. ALL60198
Weld-on kit adds an adjustable feature to standard
3/4" slider boxes. Slider boxes
commonly used for trailing arms,
ALL60048 Panhard bars and upper links can
3/4" holes, 1/8" thick. now be quickly adjusted with a
wrench, socket or possibly a remote
adjuster. 3/4"-16 threaded adjuster
block features a reference indicator.
54 www.allstarperformance.com
