CHASSIS

Upper Control Arm Bracket Ford 9" Truss Support ALL68330
ALL60190 Weld-on support
Bracket is flame cut from 1/2" thick adds strength to
steel, with 6" bolt spacing. Welds rear axle housing
to frame and accepts upper A-arm. and reduces unwanted
flex during extreme torque.
Constructed of 12 gauge (.108") steel. 36" long x 2" wide.
Chassis Tie Down Brackets
ALL60075 .500" DIA. .625" DIA. .500" DIA.
Leaf Spring Pad ALL56126
Steel brackets weld to chassis Welds to 3"
and provide a secure mounting diameter rear 2.500"
location to hook a tie down strap or end tube and 1.375"
winch cable. Package of 2. 2.875"
works with most 4.375"
5.750"
leaf springs. Sold each.
Transmission Mount Bracket
ALL38072 Lower Spring Cup
May be welded to chassis to support ALL56124
manual or automatic transmissions. Welds to 3" diameter rear end
Steel bracket is 1/8" thick with 1" x 7/16" tube and works with conventional
slots for mounting bolts.
5" coil springs. Length is 7". Sold each.
Driveshaft Loop
Leaf Spring Slider Box
ALL69000 ALL60034
Universal Leaf spring slider box replaces
driveshaft loop conventional leaf spring shackles
contains the driveshaft to enable effortless suspension
if a yoke or U-joint fails. movement and prevent binding. Box
Loop is 1/4" thick x 2" wide mild steel may be welded, or bolted directly to chassis
and fully adjustable to fit most cars.
and includes two nylon bushings with spring mounting
hardware. Fits 2-1/2" wide Chrysler type leaf springs.
Driveshaft Loop
Replacement Bushings ALL99055
For 1979-2004 Mustangs ALL69006
Driveshaft safety loop bolts-on Leaf Spring Slider Box
to help retain the front of the ALL60035
driveshaft in the Replace rear leaf spring shackles
event of a U-joint with Allstar’s leaf spring slider box.
or other drivetrain compo- Bolt-in slider box with roller bearing
nent breakage. Black epoxy coated, all design eliminates leaf spring binding, freeing
steel loop includes mounting hardware and up car. Fits 2-1/2" wide Chrysler type leaf springs.
complete instructions. Loop is designed to fit inside
factory tunnel and work with most driveshafts up to 4" in
diameter. Adjustable Panhard Bar
Mounting Bracket ALL60185
Unwelded Driveshaft Loop Bracket welds onto 3.750" 6.000" x .500" SLOT
the rear of a 3" steel
ALL69004
axle tube to mount a
Made from 3/16" flat steel, loop Panhard bar behind 8.000"
is 9-1/2" tall, 5-1/2" wide with the axle housing. A
a 16" wide mounting strap that machined 6" slot with 5.000" 2.250"
can be cut and welded for each installation.
a sliding retainer nut makes it possible to
change roll center by adjusting Panhard bar angle with
180° Driveshaft Loop ALL69002 only one wrench. Bracket includes a 3" x 3/4"-10 bolt, two
Pre-bent 1" diameter x .083" wall mild steel 5/16" wide spacers and a flat washer.
tubing is designed for chassis style cars to help
retain the driveshaft in the event of a U-joint
failure. Loop is 10" tall overall and has a 5" I.D.
