Page 167 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

ULTRA-TORQUE TAPERED RING COMPRESSORS
FASTENER ASSEMBLY LUBE CNC-machined from 6061-T6 aluminum, ring compressors have a true radius
A must for serious engine building, moly-based lubricant for each bore size. Type 3 anodized for a long, corrosion free life, and promi-
helps achieve 5% of required pre-load on the first pull. It main- nently engraved with the bore size.
tains consistency with each subsequent cycle and eliminates Part No. Bore Size
the need for re-torquing. Ultra-Torque has an effective lubrica- ARP900-0000 4.000"
tion range of -30° to 550° F. and a load range of 500,000 PSI. ARP900-0200 4.020"
Part No. Description ARP900-0300 4.030"
ARP100-9908 0.5 Fl. Oz. ARP900-0400 4.040"
ARP100-9909 1.69 Fl. Oz.
ARP100-9910 10 Oz. With Brush Top ARP900-0600 4.060"
ARP100-9911 20 Oz. With Brush Top ARP900-0700 4.070"
ARP900-1250 4.125"
THREAD SEALER ARP900-1450 4.145"
ARP100-9904 ARP900-1550 4.155"
Product delivers a flexible, leak-proof ARP900-1650 4.165"
seal on aluminum, steel, stainless steel and plastic, ARP900-1850 4.185"
and is unaffected by coolants, water, gasoline, natural gas or LPG. PTFE-based ARP900-2800 4.280"
sealer includes rust and corrosion inhibitors, has a load range of up to 10,000
PSI and an effective lubrication range of –30° to 550° F. Sold in a 1.69 fl. oz.
container.

STEVE DORER RW MOTORSPORTS MARKETING

SUPER DAMPER TIMING POINTERS
Super Dampers are unaffected by heat and ATI’s timing pointers are used specifically for
control vibration throughout the entire RPM range. Super Damper and have up to 4 degrees of adjust-
Dampers have unique, fully captured inertia rings, ment. CNC-machined from aluminum billet and black
and patent pending elastomer O-ring mountings anodized for a professional appearance.
for unequaled engine protection. Part No. Description
Total ATI918950 SB Chevy Pointer For 6-3/8" Damper
Part No. Engine Dia. Material Balance Weight ATI918954 SB Chevy Pointer For 7" Damper
Small Block Chevy, LS1 ATI918946 SB Ford, “B” Keyway, SVO Blocks With 3/8" Bolt Holes
Aluminum/
ATI917410 283-350 6.325" Internal 6.5 lbs. ATI918947 SB Ford, “C” Keyway, SVO Blocks Wvith 3/8" Bolt Holes
Steel ATI918948 SB Ford, “B” Keyway, Stock Blocks With 5/16" Bolt Holes
283-350, Aluminum/
ATI917411* 6.325" Internal 6.3 lbs. ATI918949 SB Ford, “C” Keyway, Stock Blocks With 5/16" Bolt Holes
1.600" BBC Crank Snout Steel
Aluminum/
ATI917480 283-350 6.325" Internal 4.75 lbs.
Aluminum
ATI917780 283-350 7" Steel Internal 11 lbs.
ATI917781 283-350 6.325" Steel Internal 8.5 lbs.
283-350, 1.600 12.25
ATI917783* BBC Crank Snout 7" Steel Internal lbs.
283-350,
ATI917784* 6.325" Steel Internal 8.5 lbs.
1.600" BBC Crank Snout
ATI917776* Gen. III LS1 6.325" Steel Internal 6.0 lbs.
ATI917211* LS1, 1.483” Crank Snout 7" Aluminum/ Internal 10.75
Steel lbs.
Small Block Ford
289-351W, 3-Bolt,
ATI917511 6.325" Steel Internal 8.5 lbs.
“C” Timing Tab
289-351W, 3-Bolt,
ATI918895 6.325" Steel External 8.5 lbs.
Exc. 1982-Up 5.0L AR BODIES
ATI918900 † 302-351W, 351C 6.325" Steel External 8.5 lbs. AR Bodies have committed to provide high quality products to both the
302, 1982-93 HO, asphalt and dirt racing markets. Each panel has been designed and craft-
ATI918910 † 6.325" Steel External 8.4 lbs.
34 oz., “B” Timing Tab ed to be the most aerodynamically available, providing a winning edge,
289-351W, 28 oz.,
ATI918911 † 6.325" Steel External 8.4 lbs. while maintaining ease of installation and a competitive price. AR Bodies
“B” Timing Tab are the founding manufacturer of ABC bodies and a long time manufac-
ATI918920 † 289-351W 6.325" Steel Internal 8.5 lbs. turer of NASCAR Late Model Stock Car bodies. Available by special order
* Damper has a 2.280" counterbore to accept a dry sump drive mandrel. only, please call for pricing and availability.
† Ford 4-Bolt Front.
