SUPER CELL “200” SERIES SAVER CELL
Powder coated 20 gauge steel “Do-it-yourself” fuel cells are popular
cells house heavy duty, 3-ply with vintage/club racers. Cell's molded,
rubberized bladders with foam seamless bladder must be assembled.
baffling and quick fill flapper Powder coated fill plate, “duck foot” pick-up
valves that meet NASCAR 2000 and strainer, removable foam baffling and internal
and FIA FT3.5 specifications. Cells ball type -6AN vent valve are included. Available with single
have 1-1/2" O.D. vent valves and 1/2"/-8AN or 3/8"/-6AN outlet. Cells meet FIA FT3, SCCA and USAC
-8AN pick-ups. Not for alcohol. approval. Metal container is not included (drawing supplied).
Part No. Gallon Application Weight Length Width Height Part No. Gallon Weight Length Width Height AN Size
ATLSU222C 22 Late Model 36 lbs. 34.00" 17.50" 9.50" ATLSA110 10 15 lbs. 23.00" 12.00" 9.75" -6
NASCAR All- ATLSA112 12 16 lbs. 19.75" 17.18" 9.18" -6
ATLSU222E 22 35 lbs. 33.00" 17.00" 9.25" ATLSA115 15 18 lbs. 23.75" 17.18" 9.18" -8
Pro
ATLSA122B 22 22 lbs. 24.43" 16.31" 13.25" -8

SUPER CELL
“100” SERIES RACE CELL
Cells have powder coated, 20 gauge
steel containers and 3-layer ballistic Small capacity, 3 or 5 gallon fuel cells are suitable
nylon standard FT3 fill. Other features to a variety of racing applications. Cells feature a
include TF600 aluminum fill plate, fill and vent seamless, hard rubber bladder, include 3" aircraft-
valves, anti-surge foam baffling, and -8AN pick-up. style flush cap and are fully compatible with race gas,
Not for alcohol. ethanol and methanol blends up to 100%.
Part No. Gallon Weight Length Width Height AN Size
Part No. Gallon Application Weight Length Width Height ATLRA103 3 6 lbs. 8.00" 8.00" 15.00" -8
ATLSU115 15 Super Stock/SCCA 27 lbs. 24.50" 17.75" 9.50" ATLRA103.FIA* 3 6 lbs. 8.00" 8.00" 15.00" -8
ATLSU117-FV 17 Late Model (Howe) 30 lbs. 34.00" 17.50" 7.00" ATLRA105 5 8 lbs. 10.00" 10.00" 17.00" -8
ATLSU122C 22 Late Model/SCCA 34 lbs. 34.00" 17.50" 9.50" * Includes FIA certification sticker

DUCK FOOT FUEL TRAP
Pick up lays flat against the bottom of the fuel
SPORTS cell. The Duck Foot retains fuel around the pickup
CELL SERIES strain er for con stant feed to the engine.
Budget cells have molded, seamless Part No. Description
hard rubber bladders, regular FT3 fill, ATLTF239 -6AN
powder coated 20 gauge steel contain- ATLTF240 -8AN
ers, twin fuel pickups, -8AN outlets (unless ATLTF442 -10AN
noted), fill plates, vent valves and anti-surge
foam baffling.
Part No. Gallon Weight Length Width Height
ATLSP108* 8 25 lbs. 20.50" 12.40" 9.10" ATLTF602
ATLSP112* 12 31 lbs. 20.40" 17.75" 9.50" ATLMC615
ATLSP115 15 35 lbs. 24.50" 17.75" 9.50" FUEL CELL
ATLSP122B 22 43 lbs. 25.00" 16.75" 13.75" REPLACEMENT COMPONENTS
ATLSP122C 22 43 lbs. 34.00" 17.50" 9.50" Part No. Description
* Cell has -6AN outlet. ATLMC615 15 Gallon Steel Container, Fits All 15’s Fuel Cells
ATLMC617 17-Gallon Well Cell Powder Coated Steel Container,
34" x 18" x 8", Dirt Late Model
ATLTF207 Dipstick, 16" Long, May Be Cut To Desired Length
DLM SPORTS CELL ATLTF240-S “ScavenJet” Ready Fuel Pick-Up Hose, -8AN
Engineered for dirt late models, cells ATLTF600-8 Aluminum 6" x 10" Fill Plate Assembly, (2) -8AN Outlets
have molded, seamless rubber bladders ATLTF602 Fuel Outlet Bulkhead Fitting, -6AN With 5/16" Nipple
for superior resistance to alcohol or race
gas. Includes a -10AN pickup, internal HIGH PRESSURE IN-TANK
foam baffling, a 20 gauge powder coated ELECTRIC FUEL PUMP
steel container, grade 8 hardware, -10AN ATLCFD-104
return, -6AN vent, fill plate, “flap valve” and Compact, high pressure electric fuel pump offers
ball type rollover valve. Meets FIA FT3 specs.
100 PSI of steady, consistent fuel pressure, ideal
Part No. Gallon Weight Length Width Height Color/Metal for EFI applications.
ATLSP126CLM 26 47 lbs. 25.25" 16.85" 17.25" Red/Steel Part No. Description
ATLSP126CLM-W 26 47 lbs. 25.25" 16.85" 17.25" White/Steel Corrugated Fuel Tube,
ATLSP132BLM-W 32 56 lbs. 26.12" 19.00" 17.18" White/Steel ATLCFD-401 5/16" I.D. x 12" Long, For CFD-104 Fuel Pump
ATLCFD-504 2-Wire Standard “Wire-Thru” Bulkhead,
12 Or 14-Gauge Compatible
