SMALL BLOCK CHEVY COMPETITION SERIES 7" DEEP
WET SUMP OIL PANS Eight quart (including oil filter) pans fit
STOCK APPEARING cars with Camaro front stubs. Features six
Stock appearing, 7-1/2" deep five quart trap doors, three crank scrapers, two runners,
(including oil filter) pans incorporate 6" trap oil temperature fittings and oil check level plugs.
CHACP100LT includes a removable, louvered
doors, crank scraper and windage tray for windage tray. Pans work with stock type
effective oil control. starters and flywheels. CHACP100KO includes
Part No. Description louvered windage tray and a full length kickout.
CHACP40 SB Chevy 1957-79 Oil Pan
CHACP40R SB Chevy 1980-85 Oil Pan Part No. Description
SB Chevy 1957-85 Oil Pan
CHACP100
CHACP40RB SB Chevy 1986-Up Oil Pan,1-Pc. Rear Main Seal CHACP100LT SB Chevy 1957-85 Oil Pan, With Louvered Windage Tray
CHA40SB Oil Pump Pickup, High Volume Pump, (MELM55HV) SB Chevy 1957-85 Oil Pan,
CHACP100KO With Full Length Kickout And Louvered Windage Tray
CLAIMER 7" DEEP CHACP100RB SB Chevy 1986-Up Oil Pan
Affordable claimer pans are ideal for CHACP100LTRB SB Chevy 1986-Up Oil Pan, With Louvered Windage Tray
IMCA-style Modifieds. Seven quart (including CHA100SB Oil Pump Pickup, High Volume Pump, 5/8" Dia. (MELM55HV)
oil filter) pans are kicked out to the right Oil Pump Pickup,
side 3-1/4", include three trap doors and CHA100BB High Volume BB Chevy Pump, 3/4" Dia. (MELM77HV)
crank scraper. CHACP57LT also includes CHA1003SB Oil Pump Pickup,
horsepower-saving, removable louvered wind- High Volume BB Chevy Pump, 3/4" Dia. (MEL10555)
age tray. Compatible with stock type starters and
flywheels. COMPETITION SERIES KICKOUT
Part No. Description Steel, kickout design oil pans provide
CHACP57 SB Chevy 1957-85 Oil Pan extra ground clearance for asphalt race
CHACP57LT SB Chevy 1957-85 Oil Pan, With Louvered Windage Tray cars. Kickouts improve oil control and provide
CHACP57RB SB Chevy 1986-Up Oil Pan, 1-Pc. Rear Main Seal increased horsepower. Six trap doors, three
CHA100SB Oil Pump Pickup, High Volume Pump, 5/8" Dia. (MELM55HV) crank scrapers, louvered windage tray, oil
Oil Pump Pickup,
CHA100BB temperature fitting and oil level check plug in
High Volume BB Chevy Pump, 3/4" Dia. (MELM77HV) each pan make them a great bargain. Pans must
CHA1001SB Oil Pump Pickup, (MELM155HV), 3/4" Dia. be used with a mini-starter.
CHA1003SB Oil Pump Pickup, (MEL10555)
Part No. Description
SB Chevy 1957-85 Oil Pan, 7" Deep/9 Qt. Capacity
CLAIMER 8" DEEP CHACP101LT SB Chevy 1957-85 Oil Pan, 6-1/2" Deep/7 Qt. Capacity
CHACP106LT
Designed for stock front stub cars with SB Chevy 1957-85 Oil Pan,
the stock engine location. Each eight CHACP106KO Full Length Kick-Out, 6-1/2" Deep/7 Qt. Capacity
quart (including oil filter) pan is kicked out CHACP106LTRB SB Chevy 1986-Up Oil Pan, 6-1/2" Deep/7 Qt. Capacity
to the right side 3-1/4" with three trap doors, CHA106SB Oil Pump Pickup,
a crank scraper and oil level check plug. High Volume Pump, 5/8" Dia. (MELM55HV)
CHACP55LT includes a removable louvered Note: Champ pans will NOT work with a stock style dipstick in the block.
windage tray. Works with stock type starters Pans have a block-off on each pan rail for use on either LH or RH blocks.
Check the oil level using the supplied oil plug or use the CHAJR131 dip-
and flywheels. stick.
Part No. Description
CHACP55 SB Chevy 1957-85 Oil Pan
SB Chevy 1957-85 Oil Pan, ALUMINUM PRO SERIES KICKOUT
CHACP55LT
With Louvered Windage Tray Fully fabricated aluminum wet sump pan
CHACP55LTRB SB Chevy 1986-Up Oil Pan, With Louvered Windage Tray is 7" deep with a full length kickout on the
CHA80SB Oil Pump Pickup, High Volume Pump, 5/8" Dia. (MELM55HV) right side. Pan includes five trap doors,
Oil Pump Pickup, a louvered windage tray, inspection
CHA80BB
High Volume BB Chevy Pump, 3/4" Dia. (MELM77HV) hole and oil check level plug. Pan holds
CHA1004SB Oil Pump Pickup, (MEL10555) 10 qts. (with oil filter) and requires a mini starter.
Description
Part No.
COMPETITION SERIES 8" DEEP CHAPRO1102KO SB Chevy 1957-85 Oil Pan
Top-of-the-line wet sump pan is engineered for CHA1008SB Oil Pump Pickup, 5/8" Dia. Hi-Volume Pump
stock crossmembers or rear steer linkage. Eight CHA1703SB Oil Pump Pickup, 3/4" Dia. (MELM10555)
quart (including oil filter) pan incorporates
four trap doors, crank scraper, two runners, UNIVERSAL DIPSTICK ASSEMBLY
louvered windage tray, oil temperature fitting CHAJR131
and oil check level plug. Compatible with stock
type starters and flywheels.
Part No. Description
CHACP80LT SB Chevy 1957-85 Oil Pan, With Louvered Windage Tray Universal Dipstick Assembly fits most Champ wet sump oil pans.
CHA80SB Oil Pump Pickup, High Volume Pump, 5/8" Dia. (MELM55HV)
Oil Pump Pickup,
CHA80BB
High Volume BB Chevy Pump, 3/4" Dia. (MELM77HV)
CHA1004SB Oil Pump Pickup (MEL10555)
