WINDAGE TRAYS BILLET ALUMINUM
Louvered and screen type, stamped OIL FILTER ADAPTERS - CONT.
steel trays keep oil off of the rotating CHEVY OIL BYPASS ELIMINATOR
assembly and in the sump where it CAN20-908 CAN22-570
belongs. Available for most applications.
Mounting kit must be purchased separately. Billet Chevy block-to-filter mount replaces the stock oil
filter mount and does not have a bypass, eliminating the
Part No. Description
Windage Trays possibility of unfiltered oil entering the engine.
CAN20-908 SB Chevy Pro Plus Louvered Windage Tray
CAN20-911 SB Chevy Full Length Windage Tray Screen, LH Dipstick CHEVY REMOTE
CAN20-930 SB Ford 289-302 Windage Tray Screen, Rear Sump OIL FILTER ADAPTER
CAN20-931 SB Ford 289-302 Windage Tray Screen, Front Sump Aluminum adapter is ideal for wet sump systems where
CAN20-932 SB Ford 351W Windage Tray Screen, Rear Sump a remote filter must be used. Inlet and outlet ports are
Windage Tray Mounting Kits 1/2" NPT.
Description
Part No.
CAN20-920 Mounting Kit For CAN20-911 CAN22-580 SB and BB Chevy With Straight Inlet And Outlet Ports
CAN20-921 Mounting Kit For CAN20-908 CAN98-002 Replacement O-Ring Kit
CAN20-940 Mounting Kit For CAN20-930 Or CAN20-931
CAN20-942 Mounting Kit For CAN20-932 90° ROTATING REMOTE
OIL FILTER ADAPTERS
MAIN CAP SUPPORT GIRDLES The aluminum adapter’s 90°, 1/2" NPT inlet and outlet
Laser cut, chrome moly steel ports can be rotated, simplifying hose and fitting connec-
girdles tie all five main caps tions. Ideal when unable to use stock filter location.
together to strengthen the Part No. Description
bottom end of popular Fords. CAN22-592 Chevy, 13/16"-16 Thread and 3-1/4" Seal
Girdles clear large strokers and don’t require machining, bushings or spacers to CAN22-595 Ford/Chrysler, 3/4"-16 Thread and 2-5/8" Seal
mount. Hardware included. Louvered steel windage trays for use with main cap CAN98-004 Replacement O-Ring Kit
girdles are also available.
Application Main Cap Support Girdle Windage Tray BILLET REMOTE OIL FILTER MOUNTS
SB Ford 289-302 CAN21-060 CAN20-960 Rigid, billet aluminum remote mounts accept spin-on oil filters. Mounts
SB Ford 351W CAN21-062 CAN20-962 include two 1/2" NPT inlet and two 1/2" NPT outlet ports and may be
plumbed right-to-left or left-to-right.
BILLET ALUMINUM OIL FILTER ADAPTERS Part No. Description
CHEVY OIL FILTER BLOCK-OFF CAN22-620 Remote Oil Filter Mount, Accepts
Chevy Spin-On 13/16"-16 Filters
AND INPUT ADAPTER Remote Oil Filter Mount, Accepts
CAN22-520 CAN22-625 Ford Spin-On 3/4"-16 Filters CAN22-625
Engineered for dry sump, or wet sump oiling system
with external pump. Bolts directly into the stock Chevy REMOTE CANISTER
V-8 bypass mounting holes and includes O-rings and hardware.
OIL FILTER
Extruded aluminum filter is 6" tall
CHEVY OIL INPUT x 3-1/4" square with 1-1/16"-12
SANDWICH ADAPTERS straight O-ring ports. Stainless
Simplifies the installation of external oil pumps mounting clamp sold separately.
or Accusumps by eliminating the need for a remote Part No. Description
oil filter. Adapter has two oil input ports: one before CAN25-106B Remote Canister Oil Filter
filtration (for an external oil pump) and one after (for an CAN26-100 Replacement 4-5/8" Tall Synthetic Oil Filter Element
Accusump). CAN26-891B Stainless Steel Mounting Clamp
Part No. Description
CAN22-550 SB Chevy Oil Input Adapter CANISTER FUEL FILTER
CAN98-002 Replacement O-Ring Kit CAN25-912B
Extra high flow filter has a 4" tall billet aluminum housing
CHEVY OIL COOLER and is fitted with a 2-5/8" tall, 1 micron element. Sold com-
SANDWICH ADAPTERS plete with billet mounting clamp.
Use a remote oil cooler and retain the stock oil filter.
Adapters lower the filter 1-1/2" and accept 1/2" NPT
fittings. O-rings and hardware are included.
Part No. Description IN-LINE FUEL FILTER
SB Chevy Remote Oil Cooler Sandwich Adapter, CAN25-916
CAN22-540
Goes to Cooler Before Filtration In-line fuel filter design provides unrestricted
SB Chevy Remote Oil Cooler Sandwich Adapter,
CAN22-541 flow. Lightweight, red anodized 2-3/4" diameter x
Goes to Cooler After Filtration 4" long filter body includes clear anodized, removable
CAN98-002 Replacement O-Ring Kit end caps for filter inspection or replacement. Filter includes
1-1/16"-12 ORB ports and an 8 micron synthetic element.
