Page 228 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

SPORTSMAN AND PRO BILLET SERPENTINE DRIVE PULLEYS
MECHANICAL FUEL PUMPS Pulleys are CNC-machined from premium billet alumi-
Mechanical fuel pumps are CNC-machined from durable, num and hard coat anodized for durability. Applicable
billet aluminum and feature a high pressure/high to small block Chevy or small block Ford 351W, pulleys
flow design. Each pump is fitted with steel -8AN provide a 28.5% reduction when used together.
inlet and outlet fittings. Choose from Sportsman or Pro versions. Sportsman Part No. Description
pumps produce 70 GPH, while Pro models are offered in 100, 120 and 190 GPH CVPCVD23220 Water Pump Pulley, 3.953" O.D. Dual 3 & 5-Rib
versions. All pumps require a fuel pressure regulator. CVPCVD33220 Crankshaft Pulley, 2.825" O.D., 5-Rib
Sportsman Billet Pro Billet Pro Billet Pro Billet CVPCVD60220 Alternator Pulley, 2.700" O.D., Denso 3-Rib
70 GPH 100 GPH 120 GPH 190 GPH CVPCVD73220 Power Steering Pulley, 4.700" O.D., 5-Rib
@ 8.5-9 PSI @ 9-9.5 PSI @ 10.5-11 PSI @ 16.5 PSI
Description Part No. Part No. Part No. Part No.
SB Chevy 265-400 CVPCV2705 CVPCV2509 CVPCV2508 CVPCV2605 V-BELT DRIVE PULLEYS
SB Ford 289-351W – CVPCV2523 – –
Lightweight aluminum, double groove water pump and
REPLACEMENT COMPONENTS crankshaft pulleys, when used together, produce a 20%
Components listed below fit all CV Products Sportsman and Pro Billet, as well reduction in water pump speed for added horsepower and
as Carter Competition and Billet Racing mechanical fuel pumps. increased cooling efficiency.
Part No. Description Part No. Description
CVPSPIN-MP-2534 Diaphragm With Blue Spring (9-9.5 PSI) CVPCVD22030 Water Pump Pulley, Chevy/Ford, Double Groove, 6.375" Dia.
CVPSPIN-MP-2535 Diaphragm With White Spring (10.5-11 PSI) CVPCVD30208 Crankshaft Pulley, SB/BB Chevy, Double Groove, 5" Dia.
CVPSPIN-MP-2536 Diaphragm With Green Spring (8.5-9 PSI) Note: Uses (2) Goodyear 15310 V-belts.
CVPSPIN-MP-2540 Gasket Kit
CVPSPIN-MP-2634 Diaphragm With Red Spring (16.5 PSI)
High Flow Valve Kit, Unleaded Racing Fuel, Delrin REMOTE OIL FILTER MOUNTS
CVPSPIN-MP-2640
Material Lightweight, 6061-T6 billet aluminum mounts
allow remotely mounting the oil filter, easing
HOLLEY IDLE ADJUSTING SCREW filter changes or inspections. Left and right
CVPCV179 side, -12AN inlet ports offer increased plumbing
options, while the 1/8" NPT gauge port may be
Special, extended screw replaces the stock idle used to accept an oil pressure gauge fitting.
adjustment screw, allowing adjustments to be Part No. Description
performed by hand. Fits all Holley carburetors. CVPCV746 Remote Oil Filter Mount, Chevy 13/16", Accepts Fram HP4
Remote Oil Filter Mount, 1-1/8"-16,
CVPCV749
Accepts Fram PH3519A, AC PF897 Or Wix 51268R

CT-1 DRY FILM LUBRICANT COATED ENGINE BEARINGS
Calico Coatings full line of Clevite 77 H-series engine bearings are coated with CT-1, a dry film lubricant that increases performance and improves durability.
The coating is a blend of molybdenum disulfide, graphite and PTFE lubricants that greatly reduces coefficient of friction and increases load carrying ability. It also
reduces surface temperatures, resists fuel "wash" and protects against corrosion. Please specify bearing sizing (Std., .001", .010", .020", etc.) when ordering.
Most rod bearings are narrowed for increased fillet clearance and include an “N” in the suffix to specify.
Notes: When a "D" suffix is added to the part number, bearings include dowel pin holes, while an “X” suffix indicates bearings
with .001" added oil clearance.
Engine H Series HX Series HND Series HXND Series
Chevy
1967-02 Small Block 262, 265, 267, 302, 305, 307, 350 (Large Journal) Rod Bearings
Rod Bearings CLCCB663HN CLCCB663HXN CLCCB663HND CLCCB663HXND
Rod Bearings, 1.888" Honda Sizing CLCCB1663H CLCCB1663HXD CLCCB1663HD –
Main Bearings CLCMS909H CLCMS909HX – –
Main Bearings, 283 Crankshaft CLCMS1110H – – –
1955-67 Small Block 265, 283, 267, 302, 327 (Small Journal)
Rod Bearings CLCCB745HN CLCCB745HXN – –
Main Bearings CLCMS429H CLCMS429HX – –
1970-80 Small Block 400
Rod Bearings CLCCB663HN CLCCB663HXN CLCCB663HND CLCCB663HXND
Main Bearings CLCMS1038H CLCMS1038HX – –
1997-07 Gen. III Small Block 4.8L (294), 5.3L (325), 5.7L (346), 6.0L (365) Main Bearings
Rod Bearings CLCCB663HN CLCCB663HXN CLCCB663HND CLCCB663HXND
Main Bearings CLCMS2199H CLCMS2199HX – –
Ford
1962-01 Small Block 221, 255, 260, 289, 302
Rod Bearings CLCCB634HN CLCCB634HXN – –
Rod Bearings, 2.100" Chevy/Ford Rod CLCCB1227H* CLCCB1227HX* – –
Main Bearings CLCMS590H CLCMS590HX – –
* Exclusively for Small Block Ford applications with 2.100" (Chevy) rod journal sizing using Ford Windsor connecting rods.
