WET SUMP OIL PANS WET SUMP OIL PANS - CONT.
SB CHEVY ASPHALT FORD 2.3L
LATE MODEL OIL PANS MINI STOCK OIL PAN
Shallow, 8 quart pans are for use on late model asphalt engines. Pans have Popular with mini stock racers, oil pan is compat-
7" deep sumps, windage trays and crankshaft scrapers for excellent oil control. ible with Mustang or tube chassis. Pan has a 7"
Stamped ribs increase cooling and pan rigidity. sump depth, right side “power pouch”, highly
Part No. Description efficient windage tray and 6 quart capacity.
Steel, SB Chevy Oil Pan,
Description
Part No.
CLN11000 Pre-1980, LH Dipstick, 2-Pc. Rear Seal CLN10035 Ford 2.3L Oil Pan
Aluminum, SB Chevy Oil Pan, CLN20317 Oil Pump Pickup For CLN10035
CLN11000-AC
Pre-1980 LH Dipstick, 2-Pc. Rear Seal
CLN20321 Oil Pump Pickup For MEL10555 DRY SUMP OIL PANS
SB CHEVY DIRT LATE MODEL OIL PAN
SB CHEVY LATE MODEL OIL PAN CLN11909AC-3
Steel late model oil pan includes many of the features of other
C-Line pans plus a 1" “power pouch” on the right side. The Fabricated from aluminum, dirt late model
pouch provides an easy exit for oil thrown off of the rotating dry sump oil pan combines a 1" “power
assembly and can add up to 10 horsepower. Pan has a pouch”, full length crank scraper and windage
7-1/4" deep sump. tray for effective oil control. Pan is 6-1/2"
Part No. Description deep with three pickup fittings on the right
side. Requires use of an aftermarket starter.
SB Chevy Oil Pan, Pre-1980 LH
CLN11003
Dipstick, 2-Pc. Rear Seal
CLN20322 Oil Pump Pickup For MEL10555 SB CHEVY DART/ROCKET BLOCK
DIRT LATE MODEL OIL PAN
SB CHEVY DART/ROCKET BLOCK CLN11916
LATE MODEL OIL PAN Aluminum oil pan fits dirt late model
Steel pan fits Dart/Rocket blocks with spread rails. chassis with Dart/Rocket blocks and no
The sump is 7-1/2" deep and holds 9 quarts. Full crossmember under engine. Pan is 6-1/2"
length windage tray and crank scraper offer deep with three pickup fittings on the right
maximum oil control. hand side. A reverse mount starter must be used.
Part No. Description
CLN11014 SB Chevy Dart/Rocket Block Oil Pan
CLN20322 Oil Pump Pickup For MEL10555

CP PISTONS
CP Pistons manufactures a complete line of top quality, high performance forged pistons. Recognized as an industry leader
in the field, CP Pistons include many features that are typically optional from competitor’s units, including contact reduction
grooves, accumulator grooves, double pin oilers, X-forging construction, radius domes, and a unique cam and barrel design.

SMALL BLOCK CHEVY SMALL BLOCK CHEVY
18° DOME TOP PISTONS 13° DOME TOP PISTONS
Forged, dome top pistons are fully CNC-machined High compression forged pistons, designed
and accept 1.5mm compression and 3.0mm oil rings. for use with 13° cylinder heads, are fully CNC-
Gas porting improves combustion sealing. Sold in bal- machined and accept 1.5mm compression and
anced sets of eight, complete with .927" x 2.750" chrome moly wrist pins, wire 3.0mm oil rings. Gas porting improves combus-
locks and oil rail supports. tion sealing. Sold in balanced sets of eight,
Comp. Dish/ Cubic complete with .927" x 2.750" chrome moly wrist pins and wire locks.
Part No. Bore Stroke Rod Height Dome Inch Comp. Dish/ Cubic
CPPS2151-8 4.130" 3.875" 6.000" 1.062" +2.5cc 415 Part No. Bore Stroke Rod Height Dome Inch
CPPS2153-8 4.145" 3.875" 6.000" 1.062" +2.5cc 418 CPPS2411-8 4.130" 3.875" 6.000" 1.062" -2.2cc 415
CPPS2154-8 4.155" 3.875" 6.000" 1.062" +2.5cc 420
CPPS2155-8 4.165" 3.875" 6.000" 1.062" +2.5cc 422 CPPS2412-8 4.135" 3.875" 6.000" 1.062" -2.2cc 416
CPPS2414-8 4.145" 3.875" 6.000" 1.062" -2.2cc 418
SMALL BLOCK CHEVY CPPS2415-8 4.155" 3.875" 6.000" 1.062" -2.2cc 420
13° FLAT TOP PISTONS CPPS2416-8 4.165" 3.875" 6.000" 1.062" -2.2cc 422
Fully CNC-machined, forged flat top pistons are CPPS2421-8 4.130" 3.800" 6.000" 1.100" -2.2cc 407
gas ported for improved combustion sealing. Pistons CPPS2422-8 4.135" 3.800" 6.000" 1.100" -2.2cc 408
accept .043" compression and 3.0mm oil rings. Sold
in balanced sets of eight, complete with .927" x 2.750" chrome moly wrist pins CPPS2424-8 4.145" 3.800" 6.000" 1.100" -2.2cc 410
and wire locks. CPPS2425-8 4.155" 3.800" 6.000" 1.100" -2.2cc 412
Comp. Dish/ Cubic
Part No. Bore Stroke Rod Height Dome Inch
CPPS2401-8 4.130" 4.000" 6.000" 1.000" -8.8cc 429
CPPS2402-8 4.135" 4.000" 6.000" 1.000" -8.8cc 430
CPPS2405-8 4.165" 4.000" 6.000" 1.000" -8.8cc 436
