LATE MODEL CHEVY HEAT EXCHANGER
SINGLE PASS RADIATORS RADIATORS
Late model, Chevy style aluminum Sprint Cup core design has a 13-plate heat
radiators have universal inlets to exchanger. Available to fit Chevy or Ford with
allow a variety of inlet choices includ- open or closed (no filler neck) systems.
ing 1-1/2", -16AN and -20AN. Popular Part No. Description
with late model and modified racers, CRR805-28191 Chevy 19" x 28", Open System
single pass radiators have a two row CRR805-30191 Chevy 19" x 30", Open System
core. Inlet fitting must be purchased CRR806-30191 Chevy 19" x 30", Closed System (No Filler Neck)
separately. CRR806-30194 Ford 19" x 30", Closed System (No Filler Neck)
Part No. Description
CRR800-28191 19" x 28", 1-3/4" High Outlet HIGH PRESSURE RADIATOR CAP
CRR800-31190 19" x 31, 1-3/4" Low Outlet CRR50-00003
Inlet Fittings Large, high pressure (31 lbs.) radiator cap allows higher
CRR78-00101 -16AN Male Inlet Fitting coolant temperatures without the associated loss of coolant.
CRR78-00102 -20AN Male Inlet Fitting CRR78-00102 CRR78-00104
CRR78-00103 1-1/4" Inlet Fitting LS STEAM VENT KIT CRR78-10000
1-1/2" Inlet Fitting For Std.
CRR78-00104 Engineered specifically for GM LS engines, kit
Radiator Hose allows proper air bleeding of the cooling system.
Designed to offer a clean, professional installation,
kit may be plumbed to the suction side of the water
LATE MODEL CHEVY pump or to the radiator. Includes -4AN push-lock
DOUBLE PASS fittings and braided hose. May be used on carbureted
or EFI applications.
RADIATORS
Lightweight, efficient Chevy style
aluminum radiators are for use with PORTABLE ENGINE HEATER
external oil coolers and are offered for CRR61-00017
open or closed systems. New and improved, self-contained diesel fired Porta-
Part No. Description ble Engine Heater has the ability to pre-heat the engine
CRR802-28191 19" x 28", 1-3/4" High Outlet, Open System to approximately 200°F and maintain it until the unit is
CRR802-31190 19" x 31", 1-3/4" Low Outlet, Open System switched off. The 12-volt design offers up to 7 hours of
CRR802-31191 19" x 31", 1-3/4" High Outlet, Open System operation on a full charge, while eliminating the need
for an external power source. Unit uses just 0.16-0.8
CRR804-28191 19" x 28", 1-3/4" High Outlet, Closed System
gallons per hour of fuel. May also be used in conjunc-
tion with the optional CRR61-10003 External Battery Charger for simultaneous
LIGHTWEIGHT engine pre-heating and battery charging. Quick connect hose kit and fabricated
CHEVY RADIATORS check valve must be purchased separately.
Lightweight Chevy aluminum Part No. Description
radiators reduce wet weight by Related Accessories
up to 8 lbs. Radiators incorporate CRR61-00007 Hose Box/Wheel/Folding Handle Kit, Eases Heater Transport
36mm cores, which places more CRR61-00011 5000 Series Jiffy-Tite Hose Kit
rows of tubes and fins in the same CRR61-00012 Hot Set-Up Fitting Hose Kit
CRR61-10003
External Battery Charger
area, resulting in a thinner core and NOTE: Fabricated check valve (CRR70-11000) recommended for quick
improved through-core air flow. connection, fill-ups and directional flow.
Units use the same footprint as
standard radiators, allowing direct
replacement. FABRICATED CHECK VALVE CRR70-11000
Part No. Description Specialized check valve installs inline, in 1-1/2" dia. upper
CRR811-28191 19" x 28" Double Pass, 1-3/4" High Outlet, Open System radiator hose to allow connection to a portable engine heater
CRR912-28191 19" x 28" Double Pass, 1-3/4" High Outlet, Closed System so that hot water may be circulated through the engine’s
CRR813-28191 19" x 28" Single Pass, 1-3/4" High Outlet, Closed System cooling system. Lightweight aluminum unit includes a
19" x 31" Double Pass, stainless steel, one-way valve to ensure proper coolant
CRR818-30191 flow when engine heater is activated. Valve includes
1-3/4" High Outlet, Closed System, w/Heat Exchanger
two -8AN female bungs to accept quick-connect style fit-
MODIFIED DOUBLE PASS RADIATOR tings. Quick connect fittings must be purchased separately.
CRR826-15288 DIKE AND SAFE COOLING SYSTEM ADDITIVES
Lightweight aluminum 15" x
Dike quickly stops leaks, preventing a DNF if the radiator
27-1/2" double pass radiator, is punctured, a head is cracked or a gasket fails, while
designed exclusively for Troyer
style modified chassis, is for also preventing coolant from seeping into the engine. Safe
protects the cooling system from rust, scale, lime and
closed coolant systems. Ra-
diator includes a -20 inlet and corrosion, maximizing system efficiency and prevents
overheating.
1-3/4" outlet.
Part No. Description
CRR59-00001 Dike Temporary Radiator Stop Leak, 1 Pint
CRR59-00101 Safe Radiator Conditioner, 1 Pint
