DUAL CYLINDER/FLOOR SLAVE CYLINDERS
MOUNT BRAKE PEDAL Universal slave cylinder eases clutch hookup.
ASSEMBLY CNC204SLMC Equipped with 3/16" standard brake line fittings.
Floor mount pedal assembly consists of a sturdy light- Part No. Description
weight cast aluminum bracket and a steel pedal. Accom- CNC300-BU Blue Anodized - Pull Style
Red Anodized - Pull Style
modates two master cylinders with standard 2-1/4" bolt CNC300-RU Blue Anodized - Push Style
CNC305-B
patterns and has an ad just able bal ance bar for dial-in of
Repair Kit - Pull Style
front to rear bias. Pedal is 10-1/4" long for a 5.2:1 ratio. CNC933 Repair Kit - Push Style
CNC942
Master cylinders must be purchased sep a rate ly.
CNC1312 Adjusting Rod For Push-Style Cylinder
MASTER CYLINDERS
SINGLE CYLINDER/FLOOR MOUNT Lightweight, cast aluminum and steel master
PEDAL ASSEMBLY-ROUND RESERVOIR cylinders have 1/8" NPT threads and standard
Assembly includes lightweight cast aluminum floor-mount bracket, 2-1/4" mounting pattern. Choose round or
rectangular reservoir versions. All include clevis and fittings.
steel pedal and 3/4" bore, round reservoir master cylinder. Pedal is
10-1/4" long for a 5.2:1 ratio. Bore Reservoir Master Cylinder Repair Kit
Size
Part No.
Part No.
Style
Part No. Description 5/8" Round/3" Overall Height CNC701F-5/8 CNC903R
CNC252S Bracket/Pedal/Cylinder Assembly 3/4" Round/3" Overall Height CNC701F-3/4 CNC907R
CNC250SLMC Bracket And Pedal Only 3/4" Rectangular/Short 3" Overall Height CNC702F-3/4 CNC907S
CNC701F-3/4 3/4" Cylinder Only 3/4" Rectangular/Tall 4" Overall Height CNC705F-3/4 CNC907S
7/8" Rectangular/Tall 4" Overall Height CNC705F-7/8 CNC911S
1" Rectangular/Tall 4" Overall Height CNC705F-1 CNC915S
SINGLE CYLINDER/FLOOR Part No. Description
MOUNT PEDAL ASSEMBLY- Replacement/Accessory Components
Reservoir Gasket For Round Cylinders
CNC1452
RECTANGULAR RESERVOIR CNC1458 Rectangular Cover With Twist Cap And Gasket
CNC254S CNC870-2 2 Lb. Residual Pressure Valve CNC1458
Includes floor-mount lightweight cast aluminum
bracket, steel pedal and 3/4" bore, rectangular BALANCE BAR
reservoir master cylinder. Accepts 3/16" brake line. Space saving design permits ideal front/rear
Pedal is 10-1/4" long for a 5.2:1 ratio. braking ratio.
Part No. Description
CNC1215 Balance Bar
Replacement Rod Ends
CNC1216
SINGLE CYLINDER/SWING MOUNT For CNC1215
PEDAL ASSEMBLY-ROUND RESERVOIR
Swing mount assembly includes steel pedal, light weight BALANCE BAR ADJUSTER
brack et and 3/4" bore, round reservoir master cylinder. Adjust the brake balance bar on dual master cyl in der brake systems from the
Pedal is 12" long for a 6.2:1 ratio. driver seat. By turning the knob, front/rear brake pressure can be adjusted for
Part No. Description changing track conditions.
CNC262S Bracket/Pedal/Cylinder Assembly Part No. Description
CNC260SLMC Pedal Only CNC830-2 With 2' Cable
CNC830-3 With 3' Cable
CNC830-5 With 5' Cable
ALUMINUM GAS PEDAL
HYDRAULIC CLUTCH Non-skid pedal has an integral foot rest, three mounting points,
PEDAL ASSEMBLY-FLOOR MOUNT throttle stop and return spring. Available with straight or 12°
CNC340SBU angled base.
Includes cast aluminum floor mount Part No. Description
bracket, steel pedal, 3/4" CNC round reser- CNC174 Gas Pedal Assembly, 12° Base
voir master cylinder, and blue anodized CNC174S Gas Pedal Assembly, Straight Base
pull style slave cyl in der. 10-1/4" long
pedal for a 5.2:1 ratio. THROTTLE CABLES AND ACCESSORIES
Supreme cables are made for tight radius applications.
Available in 3', 4', 5', 6', 7', 8', 10', or 12' lengths.
Part No. Description
Supreme Throttle Cable CNC842
CNC820-*
CLEVIS AND PIN CNC1457B (Specify Length) CNC846
3/16" Ball Joint,
Blue anodized replacement clevis assembly fits all CNC842 Quick Release Cable End
CNC assemblies. CNC843 3/16" Rod End, Cable End
CNC845 Clevis and Pin, Cable End
CNC846 Hook Clamp, For Quick Cable Removal
CNC847 Cable Clamp And Shim CNC847
* Specify length 4', 5' ,6' ,7' ,8' ,10' or 12'
